Material
Steel
Specifications
1.heavy expanded metal2.material:plain steel
3.type:heavy,medium&light
4.use:filter,buliding panel,fence panel.
Heavy Expanded Metal is made of high quality plain steel after being expanded on the automatic expanded machines.Because of the high strength of Heavy Type Expanded Metal, it is mostly used as walkways, ramps and catwalks of all types.
Our automatic Heavy Type Expanding Machines and our well-trained workers ensure our Heavy Type Expanded Metal with even size, level and flat surface. We can also do hot dip galvanized after expanding.
To ensure the quality of the plain steel sheet material, we have signed long term buying contract with Tangshan Steel Group, one of the best plain steel supplier in China.
Common size for heavy expanded metal |
| Thickness(mm) | Mesh size | Standard size | Weight (kg/m 2 ) | |||
| SWD | LWD | Strand width(mm) | SWM | LWM | ||
| 29> | 80 | 3.25 |
|
|
3.53
|
|
| 2.0 | 18 | 50 | 2.03 | 1800 2000 2500
|
3600 4000 5000 |
|
| 22 | 60 | 2.47 | ||||
| 29 | 80 | 3.26 | 4.42 | |||
| 36 | 100 | 4.05 | ||||
| 44 | 120> | 4.95 | 5.29 | |||
| 3.0 | 36 | 100 | 4.05 | |||
| 44 | 120 | 4.95 | ||||
| 55 | 150 | 4.99 | 2000 | 5000 | 4.27 | |
| 2500 | 6400 | |||||
| 65 | 180 | 4.60 | 2000 | 6400 | 3.33 | |
| 2500 | 8000 | |||||
| 4> | 22 | 60 | 4.5 | 1500 | 2000 |
2000-3000 | 12.84 |
| 30 | 80 | 5 | 2000-4000 | 10.46 | ||
| 38 | 100 | 6 | 2000-4500 | 9.91 | ||
| 5 | 24 | 60 | 6 | 2000-3000 | 19.62 | |
| 35 | 80 | 6 | 2000-4000 | 14.71 | ||
| 38 | 100 | 7 | 2000-4500 | 14.67 | ||
| 56 | 150 | 6 | 2000-6000 | 8.41 | ||
| 76 | 200 | 6 | 2000-6000 | 6.19 | ||
| 6 | 32 | 80 | 7 |
|
2000-4000 | 20.60 |
| 38 | 100 | 7 | 2000-4500 | 17.35 | ||
| 56 | 150 | 7 | 2000-6000 | 11.77 | ||
|
Note: Special specifications also can be made on customers’ need. |
