flattened expanded metal sheet

Specifications

1.Flattened expanded metal sheet
2.Light and heavy type
3.Easy to install
4.High quality with the reasonable price

flattened expanded metal sheet



galvanized steel expanded metal wire mesh/expanded metal mesh/expanded metal sheet/pvc coated metal sheet



Material:aluminum, platinum, brass, steel, stainless steel, nickel, etc.



Application:this product is strong and everlasting,it is widely used in filters baskets,air filtration units,medicine,medicine guards,animals cages,the protecting of electrical equipment window,safety door & room dividers,

decorative celling ,highway fence,civil building,concrete rein forcement,walkway,antidazzle panel,plaster trims,fan covers.



Specification:

Specification of Expanded Metal Mesh
Sheet Thickness	Opening in Width mm	Opening in Length mm	Stem	Roll Width mm	Roll Length mm	Weight kg/m2
0.5	2.5	4.5	0.5	0.5	1	1.8
0.5	10	25	0.5	0.6	2	0.73
0.6	10	25	1	0.6	2	1
0.8	10	25	1	0.6	2	1.25
1	10	25	1.1	0.6	2	1.77
1	15	40	1.5	2	4	1.85
1.2	10	25	1.1	2	4	2.21
1.2	15	40	1.5	2	4	2.3
1.5	15	40	1.5	1.8	4	2.77
1.5	23	60	2.6	2	3.6	2.77
2	18	50	2.1	2	4	3.69
2	22	60	2.6	2	4	3.69
3	40	80	3.8	2	4	5.00
4	50	100	4	2	2	11.15
4.5	50	100	5	2	2.7	11.15
5	50	100	5	1.4	2.6	12.39
6	50	100	6	2	2.5	17.35
8	50	100	8	2	2.1	28.26
