Help CenterSteel Grating for Oil & Gas Plant Flooring, 38x38mm Grid, 25x3mm Bar, Anti-Corrosion Epoxy Coating, 10-Year Warranty
Product Spotlights
Related Products
-
304 Stainless Steel Welded Steel Grating, 25x3mm Flat Bar, 38x38mm Mesh Pitch, Hot Dip GalvanizedNegotiableMOQ: 50 Cubic Centimeters -
Factory Direct Price, 24/7 Customer Service, Steel Grating, Hot Dip Galvanized, 30x5mm, Custom Sizes AvailableNegotiableMOQ: 50 Cubic Centimeters
-
304 Stainless Steel Grating With 32x3mm Bearing Bars Pitch 40mm for Corrosive EnvironmentsNegotiableMOQ: 50 Cubic Centimeters
-
Welded Steel Grating ASTM A123 Galvanized 100x30mm Mesh 3mm Thick Floor PlatformNegotiableMOQ: 50 Cubic Centimeters
-
Low Carbon Steel Grating Black Paint 20x3mm Flat Bar 12.5x38mm Opening for DrainageNegotiableMOQ: 50 Cubic Centimeters
Anping Xinye Metal Wire Mesh Products Co., Ltd, based in Hengshui, Hebei, China, is a professional manufacturer specializing in metal grating solutions. Our Steel Grating for Oil & Gas Plant Flooring is engineered to meet the demanding safety and durability requirements of the oil and gas industry. Featuring a precise 38x38mm grid pattern with 25x3mm bearing bars and an anti-corrosion epoxy coating, this product offers reliable performance under heavy loads and harsh environments. Backed by a full 10-year warranty, it provides long-term value and peace of mind for industrial flooring applications.
Our steel grating is manufactured using high-quality steel and advanced welding techniques, ensuring consistent strength and dimensional accuracy. The epoxy coating is applied in a controlled environment to provide uniform protection against corrosion, chemicals, and moisture. This product is ideal for walkways, platforms, trenches, and other flooring areas in oil refineries, gas processing plants, petrochemical facilities, and offshore installations.
Key Features & Technical Specifications
- Grid Pattern: 38mm x 38mm (center-to-center) – provides excellent load distribution and slip resistance.
- Bearing Bar Size: 25mm (height) x 3mm (thickness) – optimized for heavy-duty industrial flooring.
- Anti-Corrosion Epoxy Coating: Minimum 80μm thickness, applied via electrostatic spraying or dip coating, offering superior resistance to salt spray, acids, and UV exposure.
- Material: Low-carbon steel (Q235 or equivalent) with optional galvanized or stainless steel available upon request.
- Warranty: 10-year limited warranty against manufacturing defects and coating failure under normal use.
- Load Capacity: Designed to meet standard industrial load ratings (e.g., 3-5 kN/m² for walkways); custom load designs available.
- Surface Options: Plain, serrated, or with additional anti-slip inserts – customizable for safety requirements.
- Panel Size: Standard panels 6m x 1m (custom sizes available upon request).
| Parameter | Value |
| Grid Size (mm) | 38 x 38 |
| Bearing Bar (mm) | 25 x 3 |
| Coating Thickness | ≥80 μm |
| Material Grade | Q235 (or equivalent) |
| Standard Panel Length | 6 meters (customizable) |
| Standard Panel Width | 1 meter (customizable) |
| Weight per m² (approx.) | ~25 kg (varies with bar spacing) |
The anti-corrosion epoxy coating is a key differentiator for oil and gas environments. This coating system provides excellent adhesion and flexibility, preventing cracking or peeling under thermal expansion and heavy foot traffic. It also meets industry standards for slip resistance and chemical resistance, making it suitable for areas exposed to hydrocarbon spills, cleaning agents, and seawater. The 10-year warranty covers both the structural integrity and the coating performance, ensuring long-term reliability in extreme conditions.
Our steel grating is designed for easy installation and maintenance. The panels can be cut to size on-site, and the epoxy coating can be repaired with touch-up kits if minor damage occurs. Optional accessories include clamping systems, toe boards, and stair treads. For oil and gas plants, we also offer serrated bearing bars for enhanced slip resistance in wet or oily conditions.
Why Choose Anping Xinye Steel Grating?
- Manufacturing Expertise: With years of experience in metal wire mesh and grating production, we ensure consistent quality and precision.
- Quality Control: Every batch undergoes dimensional inspection, coating thickness test, and load testing before shipment.
- Global Reach: Our products are exported to numerous countries, trusted by engineering firms and EPC contractors in the oil & gas sector.
- Customization: We offer flexible options in bar size, grid spacing, coating color, and panel dimensions to meet project-specific requirements.
- Competitive Lead Time: Standard orders are typically shipped within 15-20 working days after order confirmation.
At Anping Xinye, we are committed to delivering products that combine safety, durability, and cost-effectiveness. Our factory in Hengshui, Hebei, is equipped with advanced production lines and experienced technicians. We have supplied steel grating to numerous oil and gas plant projects both domestically and internationally, receiving positive feedback on product performance and after-sales service. Our team provides technical support from selection to installation, ensuring your flooring solution meets all operational requirements.
We invite you to contact us for a quote or more detailed technical documentation. Our sales engineers are ready to assist with load calculations, custom designs, and sample requests. Protect your investment with our 10-year warranted steel grating – a reliable choice for oil and gas plant flooring.
Frequently Asked Questions (FAQ)
-
Q: What is the maximum span for this grating under a standard load?
A: For a 3 kN/m² uniform load, the maximum recommended span is approximately 1.2 meters for 25x3mm bars with 38x38mm grid. However, span capacity depends on the specific load requirements; we provide custom span tables upon request. -
Q: Can the epoxy coating withstand high temperatures?
A: The standard epoxy coating is suitable for continuous service temperatures up to 120°C. For higher temperature applications, we recommend consulting our technical team for alternative coating options. -
Q: Is the grating suitable for offshore platforms?
A: Yes, with the anti-corrosion epoxy coating and optional serrated surface, it is well-suited for offshore environments. For subsea or splash zone applications, additional coatings or galvanizing may be required – please contact us for a tailored solution. -
Q: Does the 10-year warranty cover corrosion damage?
A: The warranty covers manufacturing defects and premature coating failure (e.g., peeling, blistering) under normal service conditions. Damage caused by mechanical abuse, chemical attack beyond design limits, or improper installation is not covered. Full terms are provided in the warranty document. -
Q: What colors are available for the epoxy coating?
A: Standard colors are black and gray. Custom RAL colors can be produced for minimum order quantities. Please inquire about color options and lead time. -
Q: Can I get a sample before placing a bulk order?
A: Yes, we offer free samples of 300x300mm panels. Shipping costs are covered by the customer. Samples are typically dispatched within 3-5 working days. -
Q: How is the grating packaged for export?
A: Panels are bundled with steel straps, wrapped in waterproof paper, and packed in wooden crates for sea freight. Each bundle is labeled with product specifications and quantity. -
Q: What is the minimum order quantity (MOQ)?
A: For standard sizes, MOQ is 50 square meters. For custom sizes or special coatings, MOQ may be higher – please discuss with our sales team.
