Home > Transportation > Specialized Vehicle > Wrecker > YUTONG 4x2 Efficient 3 Ton Platform Wrecker Truck
YUTONG 4x2 Efficient 3 Ton Platform Wrecker Truck
US$ 16,900 - 24,328
MOQ: 1 Piece
Key Specifications
Get Latest Price
Fuel Type:
Diesel
Emission Standard:
Euro 4
Condition:
New
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port Tianjin port Lianyungang port Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China 25 Ton Military Quality Wrecker Tow TrucksUS$ 18,693 - 188,722MOQ: 1 Piece -
Military Technology 8 m3 Concrete Mixing TruckUS$ 33,200 - 62,600MOQ: 1 Piece
-
YUTONG 20 Ton Easy To Operate Tow Truck WreckerUS$ 83,243 - 158,870MOQ: 1 Piece
-
China Military Quality And Hot Sale 25 Ton Wrecker BodyUS$ 18,894 - 179,752MOQ: 1 Piece
-
YUTONG Road WreckerNegotiableMOQ: 1 Set
Fuel Type
Diesel
Emission Standard
Euro 4
Condition
New
Transmission Type
Manual
Dimensions (L x W x H) (mm)
7305x2280x2305
Place of Origin
Henan, China
Brand Name
YUTONG
Model Number
YTZ5070TQZFP
YUTONG 4x2 Efficient 3 Ton Platform Wrecker Truck
Product Description
Entire truck | |
Entire truck model |
YTZ5070TQZFP |
Superstructure model |
YTQZ03P |
(Lx W x H)Overall dimension |
7305x2280x2305(mm) |
Kerb weight |
4430(kg) |
Max total mass |
7300(kg) |
Wheelbase |
3815(mm) |
Rear suspension |
2475(mm) |
Departure angle |
11° |
Work platform | |
(Lx W)Overall dimension |
5500×2280(mm) |
Working stroke |
2700(mm) |
load quality |
3000(kg) |
Max tilt angle |
18° |
Working tilt angle |
0°~ 16° |
Working fold angle |
0°~ 8° |
Hydraulic winch | |
Rated towing force of winch |
36(kn) |
Cable specifications(mm×m) |
φ11x25(mm x m) |
Min. line speed of winch cable |
5m/min |
Winch quantity |
1 |
Under lift | |
Max. under-hoisting capacity |
1500(kg) |
Useful length |
.1640(mm) |
under-hoisting telescope length |
1340(mm) |
Angle of pucker |
|
Outrigger | |
Horizontal span (front/rear) |
510(mm) |
Chassis system | |
Front suspension |
1015(mm) |
Driving mode |
4×2 |
Engine model |
(Euro 4)4KH1-TCG40 |
Engine rated output |
88 (kw) |
Tire model |
7.00-16 |
Performance
|
Yutong YTZ5070TQZFP type wrecker hydraulic drive, with back, care, towing and many other features; its tilt platform structure and the rear carriage arm type, it has "a prop two" multi-functional way wrecker; and with more strong practicality and a higher price. The model not only can hold through L-type tire tool tire lifts to achieve a variety of small cars-pulling job, you can also use foldable working platforms for small and medium vehicles fast unlucky wrecker operations to achieve high speed, far wrecker operation distance |
|
Quality hydraulic global sourcing of multi-valve and balancing valve, is a strong guarantee of product performance; maximum quality of the product platform carrying three tons, the supporting arm fully extended maximum traction lifts the quality of 1.5 tons, can widely used in urban and high-speed transport wrecker rescue operations. |
|
|
Our Services
Service after sale is based on the principle of
service. We will offer the “12380”service:
service. We will offer the “12380”service:
1: After receiving the customer mobile, we will help
customer solve problem through removing the
resources of YUTONG service and reply the customer
clearly in one hours;
2: To improve the service quality all the time, in 2
working days of the end of on-sit service, we will pay
a return visit about the satisfaction of after sale
service;
3: To comprehensive systematically and
professionally maintenance and repair for the
customer product, we will have 3 times On-Site
Inspection forwardly in warranty period;
8:The service engineer will solve problem in 8 hours
after getting to on-sit. If the problem is not solve ,the
service engineer can not leave the on-sit;
0: To eliminate customer worries, from receiving
order to product scrapping, YUTONG will provide
full reliance,seamless docking and service in the
period of product using.
