Home > Transportation > Specialized Vehicle > Wrecker > YUTONG 20 Ton Easy To Operate Tow Truck Wrecker
YUTONG 20 Ton Easy To Operate Tow Truck Wrecker
US$ 83,243 - 158,870
MOQ: 1 Piece
Key Specifications
Get Latest Price
Fuel Type:
Diesel
Emission Standard:
Euro 3
Condition:
New
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port Tianjin port Lianyungang port Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Military Quality And Hot Sale 25 Ton Wrecker BodyUS$ 18,894 - 179,752MOQ: 1 Piece -
YUTONG Road WreckerNegotiableMOQ: 1 Set
-
YUTONG 50Ton New Generation Of Right Hand Wrecker Tow Trucks For SaleUS$ 28,953 - 189,250MOQ: 1 Piece
-
YTZ5507TQZ40E Five Axles Road WreckerNegotiableMOQ: 1 Set
-
YTZ5255GJB33E Concrete Mixer TruckNegotiableMOQ: 1 Set
Fuel Type
Diesel
Emission Standard
Euro 3
Condition
New
Transmission Type
Manual
Dimensions (L x W x H) (mm)
8810X2500X3290
Place of Origin
Henan, China
Brand Name
YUTONG
Model Number
YTZ5197TQZ40EN
YUTONG 20 Ton Easy To Operate Tow Truck Wrecker
Product Description
Main Technical Parameters of Road Wrecker Truck
Overall dimension of complete vehicle (mm) |
8810×2500×3290 |
Wheelbase (mm) |
5600 |
Wheel track of front wheel (mm) |
2022 |
Wheel track of rear wheel (mm) |
1830 |
Maximum under-pulling capacity (kg) o |
19000 |
Maximum hoisting-pulling capacity (kg) |
12000 |
Furthest hoisting-pulling capacity (kg) |
5800 |
Telescopic stroke of boom (mm) |
2500 |
Maximum hoisting height (mm) |
5500 |
Maximum lift angle (°) |
35 |
Rated tractive force of winch (kN) |
80 |
Number of winch |
2 |
Maximum under-hoisting capacity (kg) |
6400 |
Maximum under-hoisting capacity in full-extension condition (kg) |
5000 |
Maximum efficient under-hoisting length (mm) |
3900 |
Telescopic stroke of support arm (mm) |
925×2 |
Folding angle of support arm (°) |
-7~+92° |
Kerb mass of entire vehicle (Kg) |
14500 |
Maximum vehicle speed(km/h) |
90 |
Maximum gradeability (%) |
≥20 |
Minimum turning diameter (m) |
≤23 |
Minimum ground clearance (m) |
≥260 |
Approach angle(°) |
16 |
Departure angle (°) |
15 |
Performance
|
1.The tow truck for sale adopts integrated type structure. According to CAE analysis, its working devices have reasonable and matching design and reliable operating performance. . 2.The tow truck for sale chassis manufactured by China National Heavy Duty Truck Group Co., Ltd (a famous brand in China), has strong bearing capacity and especially its adaptability is a more competitive advantage as the road-block removal truck has a outstanding feature that is load transfer. 3.Adopting dual-circuit braking system and auxiliary engine braking system, the tow truck for sale has strong road adaptability. 4.All of the hydraulic systems of working devices of the tow truck for sale adopt both domestic and foreign brands. Both of luffing cylinder and support arm swing cylinder are equipped with safe and reliable balancing valves, greatly improving the safety performance of the working devices. |
|
5.All moving parts of tow truck for sale are equipped with self-lubricating bearings. Especially, the crossarm position of the support arm, which bears larger force and acts frequently, is equipped with enhanced self-lubricating bearing besides retaining the lubricating oil channel. This greatly improves the service life, but also reduces the maintenance frequency.
6.The thin-type extended support arms of this tow truck for sale, which are equipped mainly for the public traffic vehicles, adopt high-strength steel design, greatly enhancing the strength performance and effectively solving the problem of low chassis of public traffic vehicles. 7.When the arms are used together with reliable L-shaped tire holding tools, the operating performance of heavy duty tow truck for sale will become more superior.
8.The operating mechanism of tow truck for sale is positioned at the rear part of the vehicle and it can be operated at both sides. Moreover, its operating handle is designed with an angle of 60 degree, which makes the operation more convenient and comfortable. |
|
|
Our Services
Service after sale is based on the principle of
service. We will offer the “12380”service:
service. We will offer the “12380”service:
1: After receiving the customer mobile, we will help
customer solve problem through removing the
resources of YUTONG service and reply the customer
clearly in one hours;
2: To improve the service quality all the time, in 2
working days of the end of on-sit service, we will pay
a return visit about the satisfaction of after sale
service;
3: To comprehensive systematically and
professionally maintenance and repair for the
customer product, we will have 3 times On-Site
Inspection forwardly in warranty period;
8:The service engineer will solve problem in 8 hours
after getting to on-sit. If the problem is not solve ,the
service engineer can not leave the on-sit;
0: To eliminate customer worries, from receiving
order to product scrapping, YUTONG will provide
full reliance,seamless docking and service in the
period of product using.
About Us
Inspect vehicles before sale
Laser welding
Examine the metalic
elements
elements
SGS certification
Trade Shows
|
|
|
|
|
|
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2001
Factory Size
Above 100,000 square meters
Total Employees
Above 1000 People
