The Atmosphere And Beautiful Appearance OF YUTONG Landfill Compactor For Sale
The Atmosphere And Beautiful Appearance OF YUTONG Landfill Compactor For Sale
Main Technical Parameters of Landfill Compactor
Overall dimension of the landfill compactor (mm) |
7275×3094×3710 (Transportation height: 3510) |
Engine model of landfill compactor |
SC8D180.1G2B1 |
Rated Power of Engine (Kw) |
132 |
Rated speed of engine (rpm) |
2200 |
Operating mass of landfill compactor (kg) |
20000 |
Rolling width of landfill compactor (mm) |
2986 |
Shovel height of landfill compactor (mm) |
1685 |
Shovel width of landfill compactor (mm) |
3094 |
Shovel hoisting height of landfill compactor (mm) |
1000 |
Shovel ground-cutting depth of landfill compactor (mm) |
150 |
Maximum grade ability of landfill compactor |
100 |
Ground clearance of landfill compactor (mm) |
420 |
Maximum travel speed of landfill compactor (km/h) |
11 |
![]() |
![]() |
Performance Characteristics of the landfill compactor
| 1.The landfill compactor adopts hydromechanical transmission, front and rear four-wheel drive and four-wheel braking. |
| 2. The landfill compactor adopts military quality hydraulic torque converter and power-shift gearbox; the clutch friction plate is installed externally, which is easy for maintenance; two forward gears and two backward gears are suitable for the harsh conditions in landfill; meanwhile, the gearbox can automatically realize spontaneous out-of-gear when braking, and can automatically connect the gear when releasing the braking, so as to avoid damaging transmission system during braking |
| 3. The hydraulic system of the whole machine adopts German DIN standards. Its "Cone-Ο" double seal has good leakproofness and strong anti-leakage. |
| 4.Firm vehicle frame of the landfill compactor with inclosed, flat-bottom and box-shaped structure can reduce driving resistance, completely eradicate fires and prevent garbage from entering into the cabin. |
| 5.The landfill compactor is equipped with an auxiliary disinfection spray system with the ability of drug-corrosion prevention. The spray dosage is adjustable. Meanwhile, it is equipped with electrical protection device for nozzle clogging. |
| 6. NO-Spin differential mechanisms (with automatic interlock) are equipped within the rear drive axles. |
| 7. The landfill compactor of the landfill compactor is equipped with an auxiliary disinfection spray system with the ability of drug-corrosion prevention. The spray dosage is adjustable. Meanwhile, it is equipped with electrical protection device for nozzle clogging; |
| 8. The cab of the landfill compactor is equipped with roll over protection structure (ROPS), becoming firm and safe. |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
|
![]() |
|
