YUTONG Plain Coloured Green Big Energy-efficient Road Washer Trucks
- 100 Piece / Pieces per Month
- Qingdao Port Tianjin port Lianyungang port Shanghai port
- T/T D/P D/A
You May Like
Product Details
| Condition | New | Place of Origin | Henan, China | |
| Brand Name | YUTONG | Model Number | YTZ5160TXS20E | |
| Dimension(L*W*H) | 8590x2490x2980 | Weight | 11650 | |
| Certification | ISO | Warranty | 12months/2000hours | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
YUTONG Plain Coloured Green Big Energy-efficient Road Washer Trucks
Main Technical Parameters of Road Washer Trucks
Item | Unit | YTZ5160TXS20E | |
Cleaning Operation Of road washer trucks | Maximum cleaning & sweeping width (Including cleaning & sweeping width of curb) | m | 4.1 |
Cleaning and sweeping speed | km/h | 3~10 | |
Rated pressure of cleaning water | Mpa | 14 | |
Rated flow of cleaning water | L/min | 137 | |
Sweeping Operation Of road washer trucks | Sweeping width | m | 3.5 |
Sweeping speed | km/h | 3~15 | |
Cleaning speed | km/h | 3~20 | |
Maximum cleaning capacity | square meters/h | 70000 | |
Discharge angle | ° | ≥48 | |
Cleaning width under low pressure Of road washer trucks | m | 24 | |
Total volume of cleaning water tank | L | 9000 | |
Total volume of dustbin | L | 7000 | |
Maximum vehicle speed Of road washer trucks (full load) | km/h | 90 | |
Maximum grade ability Of road washer trucks | % | 30 | |
Braking distance Of road washer trucks (30 km/h with full load) | m | ≤10 | |
Min. turning diameter Of road washer trucks | m | 19 | |
Kerb mass of entire vehicle | kg | 11650 | |
Max. gross mass Of road washer trucks | kg | 16000 | |
Wheelbase Of road washer trucks | mm | 5000 | |
Angle of approach | (°) | 20 | |
Angle of departure | (°) | 15 | |
Minimum ground clearance Of road washer trucks | mm | 250 | |
Overall dimension Of road washer trucks (L × W × H) | mm | 8590×2490×2980 | |
Main Configuration of Road Washer Trucks
Item Of road washer trucks | YTZ5160TXS20E | ||
Vehicle chassis | Chassis model, type, manufacturer | Dongfeng DFL1160BX | |
Engine model, manufacturer Of road washer trucks | Dongfeng Cummins ISDE185 30 (National Ⅲ) | ||
Rated power of engine | 136kw/2500r/min | ||
Transmission model Of road washer trucks | DF6S900 | ||
Speed ratio of transmission | 1:6.446: 2:3.841: 3:2.290: 4:1.477:5:1.000:6:0.802:R:6.188 | ||
Drive axle | Single-stage, hyperbolic main gear reducer Speed ratio i=5.286 | ||
Tyre Of road washer trucks | Front wheel | 10.00-20 (10.00R20) | |
Rear wheel | 10.00-20 (10.00R20) | ||
Fuel type Of road washer trucks | Diesel oil meeting the third stage emission requirements; the selection of appropriate diesel grade is in accordance with the temperature | ||
Auxiliary engine | model, manufacturer Of road washer trucks | EQ6BT5.9-C160 Dongfeng Cummins Engine Co., Ltd. | |
Power Of road washer trucks | 118kw/2600r/min | ||
Clutch Of road washer trucks | Automobile clutch, adopting pneumatic drive and electrical automatic control | ||
 |
|
Performance Characteristics of road washer trucks
| 1.Dongfeng Tianjin DFL1160 series chassis occupies the industry's highest market share, with industry-leading reliability. |
| 2. High pressure water pump imported from Italy has high pressure resistance, large flow and long service life; Japan SMC's pneumatic system is the world's top pneumatic system brand, which is efficient, energy-saving and has reliable quality |
| 3. The ATOS manifolds & valve packs imported from Italy provide reliable quality, without any leakage and failures; auxiliary engine, in which Dongfeng Cummins invested heavily, has advanced technology and reliable quality; radiator of auxiliary engine, with reinforced design and the largest area in the industry, can guarantee the normal operation even at high temperature above 40 ℃, so as to avoid the industry's ubiquitous high temperature problem of auxiliary engine. |
4.Water pump drive Of road washer trucksadopts pneumatic gear clutch, which will cut off the power of high pressure water pump under the mode of cleaning, so as to extend the service life of the high pressure water pump. |
| 5. The road washer trucks adopts Dongfeng Cummins auxiliary engine with air-to-air intercooler that makes diesel burning more fully, not only saving fuel, but also realizing good emissions, truly reflecting the design concept of fuel-efficient and environmental friendly. |
| 6. The suction system Of road washer trucks has reasonable matching and low energy consumption after being optimized by academician workstation; the design widely applies software of finite element analysis, not only making components meet the stiffness and strength requirements, but also greatly reducing the weight, realizing the most efficient operating economics. |
| 7. The road washer trucks adopts the latest research results of noise control of Zhengzhou Environmental Engineering Research Center, so its noise control has achieved the best level in the industry, minimizing the environmental impact. |
| 8. The garbage tank road washer trucks is sealed by imported foamed rubber, with good performance in resistance to compression deformation and in resistance to corrosion, resulting in no omission of garbage during the process of sweeping and transportation, so as to secondary pollution. |
| 9. The set of emergency stop switch and selector switch for the control system and the interlocking design in the program can effectively prevent the misuse or malfunctionpan. |
| 10. The dual protections by hydraulic lock design and safety support can prevent the sudden falling of dustbin during the maintenance and repair process, so as to avoid personal injury; when lifting the dustbin to dump the garbage, open the rear door first through the automatic control program, so as to prevent lifting the dustbin with full load, avoiding rollovers. |
| 11.Automatic alarm for vehicle faults; computer detects faults and judges the faults accurately, so it can instantly catch the fault source; the turn angle of cab is large, resulting in sufficient space for maintenance. |
| 12. Remote starting and stopping devices can avoid the problem of making such operations within a tipping cab; due to eversion-type outside plate of front wall of the cab . road washer trucks, operator can take routine maintenance without the need of flipping the cab. |
| 13.Two repair doors road washer trucks are set on right and left sides of the engine hood, making the routine maintenance of auxiliary engine become more convenient and close enough. |
|
|
|
|
|
|
| |
|
| |
