Military Quality 156Hp Engine Chinese Bulldozer
Product parameter
No. |
Model |
YT140-1 |
||||
1 |
Blade Type |
TiltStraight titling blade |
Angular blade |
Coal blade |
||
2 |
Complete vehicle operating weight (kg) |
16200 |
16300 |
16500 |
||
3 |
Blade weight (kg) |
1800 |
2000 |
2200 |
||
4 |
Dimensions (mm)(Length × Width × Height) |
5099×3297×2842 |
5180×3762×3042 |
5680×3790×3042 |
||
5 |
Dimensions (mm), including ripper(Length × Width × Height) |
6019×3297×2842 |
6100×3762×3042 |
6600×3790×3042 |
||
6 |
Minimum turning radius |
4000 |
4150 |
4100 |
||
7 |
Gradability |
Longitudinal 30º, transverse 25 º |
Longitudinal 30º, transverse 25 º |
Longitudinal 30º, transverse 25 º |
||
8 |
Ground pressure (kPa) |
61.8 |
62.1 |
62.9 |
||
9 |
Ground clearance (mm) |
353 |
||||
10 |
Flywheel power (kW) |
104 |
||||
11 |
Max. drawbar pull (kN) |
128 |
||||
12 |
Engine Parameters |
Items |
Parameters and Description |
|||
Model/type |
WD10G156E26/Inline, vertical, water-cooled, 4-stroke, turbocharged, direct-injection |
|||||
Manufacturer/origin (manufacturer) |
Weichai Power Co., Ltd. |
|||||
Applicable ambient/elevation(℃/m) |
-30℃—50℃/3000 |
|||||
Number of cylinders- Bore × Stroke (mm) |
6×126×130 |
|||||
Displacement piston, L |
9.726 |
|||||
Rated power, kW |
115 |
|||||
Rated revolution (r/min) |
1800 |
|||||
Maximum torque/revolution (N.m/rpm) |
780/1100~1200 |
|||||
Torque reserve coefficient |
20% |
|||||
Min. fuel consumption rate, g / (kW.h) |
215 |
|||||
Lubricating oil consumption rate, g/(kW.h) |
0.4 |
|||||
Emission standard |
Euro II |
|||||
Starting method |
electrical starting 24V |
|||||
Starter power, kW |
6.6 |
|||||
Generator model/origin (manufacturer) |
612600090206D |
|||||
Generator voltage/current, V/A |
28/55 |
|||||
Battery model/origin (manufacturer) |
6-QW-120B/Shanghai Johnson |
|||||
Battery type |
Maintenance free |
|||||
Air filter type |
3-stage, dry |
|||||
Features of 140-1 Bulldozer
1. Great tractive force and good adhesion property.
2. More reliable transmission, higher transmission efficiency, simpler structure and more convenient maintenance, compared to hydraulic bulldozer.
3. Powerful engine, low oil consumption and low noise, accommodating various operating conditions with an elevation below 4000 m.
4. Travel system with swing rocker beam (equalizer). The rocker beam is designed with semi-rigid suspension, which may ensure operating stability and smoothness of the complete machine, but also may effectively reduce the impact of the operating surface to the transmission system and cab, and improve safety and comfort.
5. Properly matched transmission ratio of transmission system with engine to make full use of engine power.
6. Central lubricating system provided for bad operating conditions.
|
"12380"Service after sale. We can offer: 1.After receiving the customer mobile, we will help customer solve problem through removing the resources of Yutong service and reply the customer clearly in one hours; 2: To improve the service quality all the time, in 2working days of the end of on-sit service, we will pay a return visit about the satisfaction of after sale service; 3: To comprehensive systematically and professionally maintenance and repair for the customer product, we will have 3 times On-Site Inspection forwardly in warranty period; 8:The service engineer will solve problem in 8 hours after getting to on-sit. If the problem is not solve ,the service engineer can not leave the on-sit; 0: To eliminate customer worries, from receiving order to product scrapping, Yutong will provide full reliance, seamless docking and service in the period of product using. |
|
|
|
|
|
Yutong Heavy Industry is China's top 500 enterprises Yutong Group's core subsidiary, is a leading supplier of specialized mining, infrastructure and sanitation machinery and equipment package of solutions. The company is the cradle of Chinese construction machinery design and manufacturing, since 1958, China's first hydraulic torque converter, the first power shift transmission, the first self-propelled scrapers, the first large horsepower tire type tractors, more than 30 "China's first" all born here! factory occupies 2102 acres, with more than 3,000 people, including more than 470 man-made construction machinery senior technical staff, and has academician workstation and provincial enterprise technology center. Yutong Heavy Industries as a quality supplier of PLA, every year a large loaders and bulldozers to the military. We also provide the United Nations had as loaders, bulldozers and wreckers, and obtained the creation of the United Nations awarded the Star of Science Award. Our company is China's first loader KD line exporter, currently this KD line services in Iran, the annual amount of 300 assembly, and its products can cover the Middle East, many countries such as: Saudi Arabia, Turkey and Azerbaijan. Also Our rotary drilling rig, successfully sold to the United States five devices, and job conditions in Alaska minus 50 degrees. Our product is in Africa an affirmative president of Nigeria, the African business people and our next president our photo equipment. Our sanitation garbage package of solutions and services in Ghana is the country for the African brothers to improve their living environment contribute our part. In South America, Cuba and Venezuela, we are the government's long-term strategy for its suppliers. Rotary Drilling Division I Participation in 2008 Olympic Games in the Bird's Nest construction work, and successfully laid the first pile. |
We are military equipment supplier, our original facotry is founded at 1958. Good quality and competitive price is our advantage.
For quality guarate, we give one year guarantee, and with 24hours response principle for better service. We have more than 30 agency all over the world, you can get the most convenient service by nearest agency.
We accept T/T, L/C, D/P, D/A,even L/G. |
|
