Hot Sale Small Rock Saw Attachment For Skid Steer Loader
Specifications |
|
|
Rated operating capacity(kg) |
1000 |
|
Tipping load(kg) |
1900 |
|
Bucket capacity(m3) |
0.5-0.6 |
|
Operating weight(kg) |
3400 |
|
Max. travel speed(km/h) |
12 |
|
Hydraulic pump flow(L/min) |
75 |
|
Fuel tank capacity(L) |
90 |
|
Tires |
12/16.5NHS |
|
Overall dimensions(mm) |
3490×1820×2150 |
|
Dimensions | ||
Height at maximum extension |
4070(mm) |
|
Height to bucket hinge pin |
3100(mm) |
|
Width with bucket(mm) |
1880 |
|
Track width(mm) |
1500 |
|
Wheelbase(mm) |
1085 |
|
Ground clearance(mm) |
200 |
|
Dump angle |
30° |
|
Dumping height(mm) |
2450 |
|
Rollback at ground |
26° |
|
Angle of departure |
20° |
|
Engine |
|
|
Model |
Mitsubishi S4S |
|
Net power |
75hp/2500rpm |
|
Type |
4 Cylinder in-line, Water cooled, 4 stroke, Diesel engine |
|
Displacement(L) |
3.2 |
|
Standard equipment |
Deluxe enclosed operator cab |
|
Hydraulic joystick controls | ||
Standard bucket |
|
|
Auxiliary hydraulic couplers | ||
Optional equipment |
starting assist system for extreme cold weather |
|
Cab fitted with a heater as standard | ||
Air conditioner | ||
2-speed transmission system | ||
High-flow hydraulic system | ||
| 1.MitsubishiS4S-DTengine, 4 strokes, naturally aspirated and water-cooling, all ensuring sufficient power. |
| 2.It is a drive system with the best compatibility. The imported engine boasts the features of low noise and low oil consumption, being reliable in performance and reaching Euro 3 emission standards. |
| 3.The vehicle frame adopts a compact structure design with high strength and heavy loading, and the thickened integrated chassis has improved the capacity of anti-vibration. |
| 4.While the vehicle body is small buthaving huge power, its 360 skidding and steering provides flexible manipulation and action. |
| 5.The drive system uses Saul duplex variable pump and Italian Wolff multi-way valve. The hydraulic pump directly connected to the engine not only improves the stability of speed control system, its huge flow also can ensure that 275 can assemble many other accessories. |
| 6.It employs the working device with heavy load. With only two control levers, operations such as traveling, steering, loading and unloading can be achieved in a fast and smooth manner. |
| 7.The automatic leveling system can ensure the efficient and safe performance of bucket in the process of lifting and descending, which is time-saving. |
| 8.The cab possesses comfortable driving space. While the ROPS and FOPS cabs are safe and reliable, the full- sealed cab is equipped with the air conditioner, and with windows in every direction, presenting wide view for the driver. |
| 9.Detachable back window is the emergency exit. |
| 10.It employs an efficient hydraulic system: full-hydraulic four-wheel drive that provides the most sufficient ground traction, making the service brake safe and reliable. |
| 11.The top pilot control valve and horizontal valve worldwide ensure that the vehicle can operate accurately even though in narrow working conditions. |
| 12.The engine with low-speed but high torque provides huge pulling force. |
| 13.The full-hydraulic brake system is safe and reliable. |
|
"12380"Service after sale. We can offer: 1.After receiving the customer mobile, we will help customer solve problem through removing the resources of Yutong service and reply the customer clearly in one hours; 2: To improve the service quality all the time, in 2working days of the end of on-sit service, we will pay a return visit about the satisfaction of after sale service; 3: To comprehensive systematically and professionally maintenance and repair for the customer product, we will have 3 times On-Site Inspection forwardly in warranty period; 8:The service engineer will solve problem in 8 hours after getting to on-sit. If the problem is not solve ,the service engineer can not leave the on-sit; 0: To eliminate customer worries, from receiving order to product scrapping, Yutong will provide full reliance, seamless docking and service in the period of product using |
|
|
|
|
|
Yutong Heavy Industry is China's top 500 enterprises Yutong Group's core subsidiary, is a leading supplier of specialized mining, infrastructure and sanitation machinery and equipment package of solutions. The company is the cradle of Chinese construction machinery design and manufacturing, since 1958, China's first hydraulic torque converter, the first power shift transmission, the first self-propelled scrapers, the first large horsepower tire type tractors, more than 30 "China's first" all born here! factory occupies 2102 acres, with more than 3,000 people, including more than 470 man-made construction machinery senior technical staff, and has academician workstation and provincial enterprise technology center. Yutong Heavy Industries as a quality supplier of PLA, every year a large loaders and bulldozers to the military. We also provide the United Nations had as loaders, bulldozers and wreckers, and obtained the creation of the United Nations awarded the Star of Science Award. Our company is China's first loader KD line exporter, currently this KD line services in Iran, the annual amount of 300 assembly, and its products can cover the Middle East, many countries such as: Saudi Arabia, Turkey and Azerbaijan. Also Our rotary drilling rig, successfully sold to the United States five devices, and job conditions in Alaska minus 50 degrees. Our product is in Africa an affirmative president of Nigeria, the African business people and our next president our photo equipment. Our sanitation garbage package of solutions and services in Ghana is the country for the African brothers to improve their living environment contribute our part. In South America, Cuba and Venezuela, we are the government's long-term strategy for its suppliers. Rotary Drilling Division I Participation in 2008 Olympic Games in the Bird's Nest construction work, and successfully laid the first pile. |
We are military equipment supplier, our original facotry is founded at 1958. Good quality and competitive price is our advantage.
For quality guarate, we give one year guarantee, and with 24hours response principle for better service. We have more than 30 agency all over the world, you can get the most convenient service by nearest agency.
We accept T/T, L/C, D/P, D/A,even L/G. |
|
