China Hot Sale 6 Ton Front End Loader Prices
Main Technical Parameters
Overall dimension (length x width x height) (mm) |
8705 x31303450 |
|
Rated load (t) |
6.0 |
|
Standard bucket capacity (m3) |
3.5 |
|
Weight of complete machine (t) |
20.1-20.5 |
|
Unloading height (mm) |
3432 |
|
Unloading distance (mm) |
1255 |
|
Sum time of three items (s) |
≤12.0 |
|
Wheelbase (mm) |
3285 |
|
Wheel track (mm) |
2310 |
|
Maximum breakout force (kN) |
185 |
|
Maximum traction (kN) |
196 |
|
Steering angle |
36º |
|
Maximum traveling speed (km/h) |
46 |
|
Minimum turning radius |
6255 |
|
Maximum gradeability (°) |
25 |
|
Engine model |
SC11CB255G2B1 |
|
Rated power of engine (kw/hp) |
187 /255 |
|
Rated speed of engine (rpm) |
2200 |
|
Maximum torque of engine (N.m) |
969 |
|
Engine displacement |
Euro2 |
|
Model of gearbox |
Yutong fixed shaft gearbox |
|
Model of torque converter |
Yutong 420 torque converter |
|
Gears of gearbox |
Four forward gears and four backward gears |
|
Model of drive axle |
Yutong military axle |
|
Load of drive axle (t) |
30 |
|
Braking way |
Caliper disc brake |
|
Tire model |
23.5-25-20PR |
|
Pressure of working system (MPa) |
17.0 |
|
Operation manner of working system |
Pilot control |
|
A/C system |
Single-cold air conditioning, installation of heating device |
Serial number |
Project |
Parameter |
|
1 |
Shovel bucket |
Fan-shaped rock bucket (welded bucket teeth, with gear sleeve) |
3.2m³ |
Fan-shaped rock bucket (without bucket teeth, whole blade) |
3.2m³ |
||
Common bucket (bolted bucket teeth, without gear sleeve) |
3.5m³ |
||
Common bucket (without bucket teeth, without gear sleeve) |
3.5m³ |
||
Coal bucket (welded bucket teeth, without gear sleeve) |
4.2m³ |
||
Coke bucket (without bucket teeth, without gear sleeve) |
4.6m³ |
||
Lightweight material large bucket (without bucket teeth, without gear sleeve) |
5.5m³ |
||
2 |
Else |
Lengthened arm |
|
Kunlun tire |
|
||
Reload common wood clip device |
|
||
Reload common pipe catching device |
|
||
Reload common bottom fork device |
|
||
Snow pushing changing device |
|
||
Quick changing bucket |
|
||
Quick changing bottom fork device |
|
||
Quick changingwood clamping component device |
|
||
Quick changingpipe graspingcomponent device |
|
||
Added concentrate lubrication system |
|
||
Add bucket automatic flat and swing arm lifting limit device |
|
||
Added spinning alarm lamp |
|
||
Antiskid chain(1 set) |
|
||
Added reverse video system |
|
||
Single rod pilot |
|
||
Reload anti-tilt cab |
|
||
Yutong yellow paint |
|
||
Carter yellow paint |
|
||
Varnish |
|
||
|
|
1.The 420 torque converter of wheel loader developed by using military technology has large capacity and wide high efficiency area. 2.Enhanced-type drive axle of wheel loader developed by using military technology has strong load capacity, which can reach 30 tons. 3.With unloading height of 3432 and unloading distance up to 1255, the wheel loader has high shoveling and loading efficiency 4.The swing-type rear axle of wheel loader is arranged centrally, with swing angle of up to ± 11°. With four-wheel drive, it has good adaptability. |
|
5.The operation of hydraulic single lever pilot control system is easy and flexible; the hydraulic control valve of wheel loader is located on the front end of front frame, so it is very convenient to take maintenance on it. 6.Due to double-pump confluence technology, the energy loss is less and the reliability is high. 7.Due to integral-type quench blades and bucket teeth, wheel loader becomes more wear-resistant and its service life becomes longer. 8.The combination of paint color is reasonable and can effectively release the driver's visual fatigue. |
|
"12380"Service after sale. We can offer: 1.After receiving the customer mobile, we will help customer solve problem through removing the resources of Yutong service and reply the customer clearly in one hours; 2: To improve the service quality all the time, in 2working days of the end of on-sit service, we will pay a return visit about the satisfaction of after sale service; 3: To comprehensive systematically and professionally maintenance and repair for the customer product, we will have 3 times On-Site Inspection forwardly in warranty period; 8:The service engineer will solve problem in 8 hours after getting to on-sit. If the problem is not solve ,the service engineer can not leave the on-sit; 0: To eliminate customer worries, from receiving order to product scrapping, Yutong will provide full reliance, seamless docking and service in the period of product using. |
|
|
|
|
|
Yutong Heavy Industry is China's top 500 enterprises Yutong Group's core subsidiary, is a leading supplier of specialized mining, infrastructure and sanitation machinery and equipment package of solutions. The company is the cradle of Chinese construction machinery design and manufacturing, since 1958, China's first hydraulic torque converter, the first power shift transmission, the first self-propelled scrapers, the first large horsepower tire type tractors, more than 30 "China's first" all born here! factory occupies 2102 acres, with more than 3,000 people, including more than 470 man-made construction machinery senior technical staff, and has academician workstation and provincial enterprise technology center. Yutong Heavy Industries as a quality supplier of PLA, every year a large loaders and bulldozers to the military. We also provide the United Nations had as loaders, bulldozers and wreckers, and obtained the creation of the United Nations awarded the Star of Science Award. Our company is China's first loader KD line exporter, currently this KD line services in Iran, the annual amount of 300 assembly, and its products can cover the Middle East, many countries such as: Saudi Arabia, Turkey and Azerbaijan. Also Our rotary drilling rig, successfully sold to the United States five devices, and job conditions in Alaska minus 50 degrees. Our product is in Africa an affirmative president of Nigeria, the African business people and our next president our photo equipment. Our sanitation garbage package of solutions and services in Ghana is the country for the African brothers to improve their living environment contribute our part. In South America, Cuba and Venezuela, we are the government's long-term strategy for its suppliers. Rotary Drilling Division I Participation in 2008 Olympic Games in the Bird's Nest construction work, and successfully laid the first pile. |
We are military equipment supplier, our original facotry is founded at 1958. Good quality and competitive price is our advantage.
For quality guarate, we give one year guarantee, and with 24hours response principle for better service. We have more than 30 agency all over the world, you can get the most convenient service by nearest agency.
We accept T/T, L/C, D/P, D/A,even L/G. |
|
