Home > Products > Plastic Profile Machine > PVC Panel Machine
PVC Panel Machine
- 36 Set / Sets per Month
- shanghai
- T/T
Product Details
Condition: | New | Application: | Plates | Plastic Processed: | PVC |
Screw Design: | Double-screw | Place of Origin: | Jiangsu, China | Brand Name: | Gaosheng PVC Panel Machine |
Model Number: | SJYF PVC Panel Machine | Voltage: | 380V 50HZ PVC Panel Machine | Dimension(L*W*H): | 16000x1200x1600mm |
Weight: | 2T | Certification: | CE |
Product Description
PVC Panel Machine
Application:
1.Household Ornament: Wall and ceiling of indent independent house bathroom
2.Public and Management Place: Toilet of building and hall
3.Common Office: Ceiling of business Place
This machine can be mainly used for producing ceiling/wall panel/board/ with the width from 100-800mm and with various thickness. Other products: plastic decorative moulding, PVC picture rail, PVC skirting, wall protection plate.
PVC Panel Machine --machine list:
nical twin screw extruder
2.Vacuum shaping system
Unique gradienter assures that the adjustment of mold is accuracy
The adjustment of shaping mold from left to right and from up to down is convenient and simple.
Independent four-section vacuum system assures the quality of product.
High effective vacuum device can realize high effective extrusion of product.
3.Haul off device
The traction pressure can be adjusted freely.
The powerful traction can meet the needs to produce high quality profile,
The traction and traction speed can be controlled remotely and the operation is very simple.
4.Automatic cutting device
Unique transverse cutting gurantees high quality kerf.
Particular alloy blade guarantees section quality of profile,
Synchronizer guarantees cutting accord with extruding.
Strong dust arrest system protect the environment.
PVC Panel Machine --data sheet:
Extruder Model | SJZ-51 | SJZ-55 | SJZ-65 | SJZ-80 |
Main Power
| 18.5KW | 22KW | 37KW | 55KW |
Final product width | 150mm | 300mm | 400mm | 600mm |
Vacuum pump power
| 4KW | 5.5KW | 7.5KW | 5.5KW*2 |
Hauling speed
| 0-4m/min | 0-4m/min | 0-5m/min | 0-3m/min |
Capacity | 100kg/h | 150kg/h | 250kg/h |
pvc ceiling sample--pictures:
After Service:
We have 1 year warranty, and lifetime maintenance. Within one year, if there is some accessory going wrong, we will send you the accessory at once, free of charge.
1). Within one month, if the machine is of any big fails, we will send you a new machine.
2). Within one year, if you send back the equipment for repair, we will be responsible for the repair, including the changes of accessories; Both of them are free of charge.
3). After one years, we offer to repair the machine, but we quire for the cost of the changed parts, not for manual cost.
4). No responsibility for man-made destroy.
5). If the buyer has any questions from our technical department, we can supply on-line service Or we can send professional engineers to help you debug them
If you are interested in our machine,please feel free to contact us.
We hope we can assist you on the machine.
Thanks a lot.
Kind regards.
Amy Su
Email:webmaster@
Contact Us
- Zhangjiagang Gaosheng Machinery Co., Ltd.
- Contact nameAmy Su
- Phone0086-512-58606818
- AddressGroup 1, Yongle Village, Zhangjiagang
