Specifications
Jinan laser cutting machine QX-40601Ideal engraving&cutting
2Cutting speed 600mm/s
3Motorised up&down worktable
QX-4060 Jinan laser cutting machine
Product Description:
1. LCD Panel
2. DSP Control System
3. Lasercut5.3 Software, Coredraw CAD
4. Various workingtable: Honeycomb or slat worktable with funnel
5. Motorized up &down worktable
6. Water pump, air pump, air blower
7. CE FDA certificate
Main Application:
Available materials: Acrylic, PVC, rubber sheet, plastic, crystal, glass, wood, bamboo, oxhorn, figuline, marble, leather, cloth, double-color board, etc. Nonmetal materials
Product Features:
1 Double Red Pointer, Wast collect box
2 with front and back feature for super-long materials processing
3 limit switch for safe processing
4 Seperate control system box
5 12 month warranty for every part of machine, 3 months for laser tube
6 CD, Video, User Manual to guide you how to install, operate, maintain machine step by step
Standard basic setting:
Water pump, air pump, exhaust fan, LaserCut software, laser tube
Optional setting:
1. Rotary clamp for engraving on cups, cylinder or round materials
2. Motorized up&down table for thick object engraving
3. Waer chiller for cooling laser tube
4. Red DOT pointer
5. Auto focus;
6. Honeycomb working table for soft material
7. Vacuum table special for soft materia
Applicable materials:
Non-metal materials such as double color board, Plexiglas, glass, acrylic, bamboo and wood, rubber, marble, granite and tiles, leather, cloth etc.
Applicable industry:
Billboards, artistic gifts, crystal ornaments, paper-cut, bamboo and wooden product, garment and leather, embroidery, decoration and upholster industry
TERMS & CONDITIONS:
1. PAYMENT TERMS: By T/T
2. DELIVERY TIME: Max. 7 -10 days after your order
3. PACKING: Seaworthy Packing
4. PRODUCT OF ORIGIN: P. R. China
5. PRODUCT GUARANTEE PERIOD: Twelve Months for every part of machine, 6 months for laser tube and lens
After-sales service:
CD, Video, User Manual to guide how to install, operate our machine.
Main Features:
1. This machine adopts the DSP data control technique, and incorporate design profile structure, which creates the durative, fast curve cutting function and optimize the shortest processing path function in the same field, so improves the working efficiency greatly.
2. It adopts the International standard linear guide rail, which makes machine running more smoothly and accurately.
3. High security. i. Detailed warning and instruction lable complied with CE; ii. Most advanced dual limit switch protection on XYZ axis, preventing the bump of laser head; iii. High quality water flow sensor to inspect water circulation in laser tube, which can protect the laser tube.
3. It adopts the most advanced focus method: dual red light positioner, which makes laser focus more easier, accurate and more personalized,no need any focusing tools.
3. It adopts up and down style by the step motor, which makes the motorized up and down working table steadier, smaller noise and faster speed and so on.
4. Front & Rear entry for long plate to pass through.
Technical parameters:
Model |
QX4060 |
Standard Laser power |
40w |
Optional Laser power |
60w,80w |
Engraving Area(mm) |
400 x 600mm/15.75in.x23.62in. |
Laser type |
CO2 Laser tube |
Cutting depth |
Acryl 0-20mm, depending on materials |
Engraving speed |
0-1000mm/s |
Cutting speed |
0-600mm/s |
Resetting positioning accuracy |
<0.01mm |
Maximum forming character |
Figure/English: 1x 1mm |
Power supply |
220V±10% 50HZ or 110V±10% 60HZ |
Software supported |
ArtCut, PhotoShop (Conversion output) CorelDraw, AutoCAD, Lasercut (Direct output) |
Main Graphic format supported |
PLT/DXF/BMP/AI (Direct output) |
Engraver for Curve surfaces |
Rotary clamp is optional and used to engrave on curse surfaces |
Water Cooling |
Yes |
Max thickness of engraved object |
280mm |
Laser tube(life hours) |
40W: 1500hours, 60w/80w: 3500-4000hours |
Gross power |
1200w |
Driving system |
Stepper motor |
Machine size |
1050*750*970mm |
G.W. |
240kg |
Packing size |
1150*850*970mm |
Recommend Consumable spares |
Laser Tube, Lens and Mirror |
Certificate |
CE, FDA |
Assistant Equipment: |
|
Optional Spare Parts: |
|
