Specifications
cnc plasma cutting machine QX-1325(CE FDA)1. model: QX1325
2. 800W variable-frequency motor
3. high precision
cnc plasma cutting machine QX-1325:
Parameters:
Working Area(XxY) |
1300x2500mm |
Cutting thickness |
0.3-20mm |
Cutting Speed |
0-8000mm/min |
Working Voltage |
3-Phase 220V |
Document Transmission Form |
USB Interface |
Plasma Generator |
American Cut-Mast |
Working Form |
Untouched Arc Striking |
Remarks |
Configured with Panasonic Servo motor; Taiwan guide rail; Taiwan servo speed reducing device. |
Features:
1.Welded lathe bed of thick-wall profiled steel, more solid and stable.
2. Reasonable lathe table design, 10 mm thickness steel plates fixed on lathe table covered by cast
sheath with spikes. Steel plates will not be damaged even under raging flame. The level difference of
whole double-deck platform remains in 0-1.5mm.
3. Advanced material inclined discharging design. All finished work pieces and fragments slide into both
sides of tunnel for safe and convenient collection.
4. Panasonic Servo motor, Taiwan servo speed reducing device and high accuracy rack transmission.
Lower noise, stable and accurate coordinate movement.
5. American Cut-Master power supply(Power: 40A/120A/200A) together with high sensitive arc pressure adjuster. Self-adjusting to choose the best distance
between plasma head and work piece automatically in order to ensure cutting accuracy.
6. Best choice for all kinds of different thickness material and heterotypic sheet cutting.
