OK-005 Automatic Carbonated drinks making machine
- 4 Set / Sets per Month
- shanghai port for Carbonated drinks making machine
- T/T Credit Card
- Cheapest Automatic Bottle Blowing Machine Prices/factory price automatic bottle shrink wrapping machine
- PET bottle making machine/nice plastic bottle making machine price/high quality plastic bottle blowing machine
- Top quality china automatic machines to make plastic bottles/bottle blowing machinery/Pet Bottles Blowing Machine 750ml
- Chinese PET water bottle blowing machine/equipment / automatic bottle Blowing machinery
- Low price Beverage drinking PET bottle blowing machinery/fully automatic pet bottle blowing machine
- high quality bottle blowing machine/automatic shrink wrapping machine/water bottle blowing machine
Product Details
Condition: | New | Application: | Beverage, Food, Other, Beverage, Food, Machinery & Hardware, Carbonated drinks making machine | Packaging Type: | Bags, Barrel, Bottles, Case, Other, Bags, Barrel, Bottles, Case, Carbonated drinks making machine |
Packaging Material: | Glass, Plastic, Wood, Other, Glass, Plastic, Wood, Carbonated drinks making machine | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 380V | Power: | 2.2KW, 3.7KW , 4.5KW , 5.5KW , 7.5KW | Place of Origin: | Shanghai, China |
Brand Name: | OK Machinery | Model Number: | BCGF | Dimension(L*W*H): | 2200X2100X2200MM |
Weight: | 1900KG , 2500KG , 3500KG | Certification: | CE, CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Carbonated drinks making machine
Carbonated Beverage Filling machine
1.Washing,Filling,Capping
2.Controlled by PLC
3.Used for Beverage/water/juice
4.CE,ISO
Carbonated Beverage Filling machine
Full automatic Carbonated Beverage Filling Machine/line
Products Introduction:
Juice Bottling Machine / Pure Water Production Line-user:
This CGF Wash-filling-capping 3-in-1unit:Beverage Machinery is used to produce polyester bottled mineral water, purified water, alcoholic beverage machinery and other non-gas beverage machinery. The CGF Wash-filling-capping 3-in-1unit:Beverage Machinery can finish all the process such as press bottle, filling and sealing, it can reduce the materials and Outsiders touch time, improve the sanitary conditions, production capacity and economic efficiency.
Characteristics:
1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.
Carbonated drinks making machine model list :
Technical Data | |||||||||
Model | CGF14124 | CGF18186 | CGF24248 | CGF323210 | |||||
The number of Washing, Filling, Capping | 14-12-4 | 18-18-6 | 24-24-8 | 32-32-8 | |||||
Producing capacity; | 2000-4000 | 5000-7000 | 8000-12000 | 12000-15000 | |||||
Applicable bottle specifications (mm) | φ=50-108 H=170-340 330ml-2.25L | ||||||||
Pressure (kg/cm2) | 2~3 | ||||||||
Motor power (kw) | Main motor 1.5kw | Main motor 2.2kw | Main motor 3kw | Main motor 4kw | |||||
Outside vacuum pump power (kw) | 0.75 | 1.1 | 1.5 | 2.2 | |||||
Overall dimension (mm) | 2100x1400x2500 | 2460x1720x2650 | 3100x2100x2650 | 3500x2500x2650 | |||||
Weight(kg) | 2500 | 3500 | 4200 | 5500 | |||||
Technical Data | |||||||||
Model | CGF404010 | CGF484812 | CGF606015 | ||||||
The number of Washing, Filling, Capping | 40-40-10 | 48-48-12 | 60-60-15 | ||||||
Producing capacity: | 16000-20000 | 20000-24000 | 25000-30000 | ||||||
Applicable bottle specifications (mm) | φ=50-108 H=170-340 330ml-2.25L | ||||||||
Pressure (kg/cm2) | 2~3 | ||||||||
Motor power (kw) | Main motor 7.5kw | Main motor 9.5kw | Main motor 12kw | ||||||
Outside vacuum pump power (kw) | 2.2 | 3 | 4 | ||||||
Overall dimension (mm) | 4600x1800x2650 | 5200x4500x3400 | 6500x4500x3400 | ||||||
Weight(kg) | 6800 | 7600 | 9800 |
Carbonated drinks making machine photos :
Shanghai OK machinery Co., Ltd. was established in 2000, It's a professional manufacturer of liquid food and beverage equipment.
We have good experience especially in filling and capping technology and they provide customized service and turnkey project.
The products scope as below:
PET bottle filling machine,
As : PET bottle water , PET bottle juice , PET bottle cola , PET bottle wine oil .....
Glass bottle filling machine,
As : glass bottle beer , glass bottle cola , glass bottle juice
Capping machine,
Pet cap , metal cap , crown cap
Bottle washing machine,
Water treatment system
Oil filling machine/piston filler,
Other bottle filling machine,
beer filling machine , beer filler , beer equipment
Labeling machine,
Film shrinking wrap packing/package machine,
Bottle unscrambler,and some drinks production line auxiliary.
