Three Phase DIN-Rail M-bus Energy Meter

FOB Price

Negotiable / Piece

500 Pieces(Min. Order)

Port Shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	YTL, YTL(M-bus energy meter)
Model Number	D519003	Display Type	Digital Only
Phase	Three Phase	Measuring Energy Range	5(30)A 10(40)A 20(80)A 10(100)A, 5(30)A 10(40)A 20(80)A 10(100)A
Accuracy Class	1.0, 1.0	Output Voltage	3220/380V, 3230/400V, 3220/380V, 3230/400V
Operating Temperature	-25~+50℃, -25~+50℃	Dimensions	122.511565mm

Product Description

Specifications

Three phase DIN-Rail M-bus energy meter
1-Max. current reach to 100A
2-M-BUS (IEC62056-21)
3-CE certificate

Three phase DIN-Rail M-bus energy meter

As a professional manufacturer, YTL designs and produces M-bus energy meter which are cost-efficient and ideal for the use in solutions for AMR/AMI at residential as well as industrial applications.

YTL is devoted to develop and design all types of M-bus energy meter, concentrators and solution applications. With a combined design of the special accessories, we have successfully developed series of competitive products of small size, multifunction, low power consumption and excellent performance. We offer a one-to-one service to our partners. With annually over 68 projects that are successfully finished and holding over 200 patents of design rights, we are also advanced in the technology and patents of current sampling.

1.Product Details
Product Name		Three phase DIN-Rail M-bus energy meter
Installation type		din rail
Module No.		D519003 (M-bus energy meter)
Brand		YTL (M-bus energy meter)
Rated Current		5(30)A 10(40)A 20(80)A 10(100)A
Reference Voltage		3220/380V, 3230/400V
Frequence		50-60Hz
Display Mode		LCD
Accuracy		1.0
Impulse Constant		800/1600imp/imp/kWh
Start Current		0.004Ib
Connection Mode		direct mode
Communication& Protocol		M-bus
Power Consumption		≤0.6W; ≤0.3VA
Material of meter case		PC
Size		122.511565mm
Certificate		CE ISO9001
Standard		IEC62052-11 IEC62053-21
2.Functions and characteristic
A. Three phase din rail meter with M-bus communiction
B.
C.
…
3.Outer and mount dimension:

4.Wiring diagram:

5.Transaction Information
MOQ	500pcs
Sea Port	Shanghai or Ningbo
Payment Terms	TT prepayment
Supply Ability	50,000pcs per month
Delivery time	20-25 days
Normal Package	white or colorful box for M-bus energy meter

If you are interested in our Three phase DIN-Rail M-bus energy meter, pls feel free to contact us at any time.
