Home > Products > Control cable > LiHH LSZH IEC 60754 Control Cable 16 AWG 18
LiHH LSZH IEC 60754 Control Cable 16 AWG 18
- Shenzhen Port
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | BDK,Bendakang | |
| Model Number | KVV,KLVV, LSZH | Shielding | Other, SWA or STA or copper braided screen or tinned copper wire screen | |
| Conductor Material | Other, Class 1/2 annealed bare copper solid or strands or Class 5 fine anneal | Jacket | PVC | |
| Insulation Material | PVC |
Product Description
Specification:
1.Voltage Rate:300/500V, 450/750V
2.Cores:Twisted Pair 1~50 pairs or Triple 1~20
3.Range of Nominal cross section:0.50 mm2 ~2.5 mm2
4.Application
It is applicable to inspection instruments connection and the signal transmission of electronic computer system, monitoring loop, automatic control system.
5.Standard:IEC60092, BS5308, TICW6-2009
6.Constructions
Conductor: Class 1/2 annealed bare copper solid or strands or Class 5 fine annealed copper wire
Insulation: PVC, XLPE, PE
Armore or Shield (optional): SWA or copper braided screen or tinned copper wire screen (individual or overall screen)
Sheath: PVC
7.Max. Operating Temperature:70°C, can be 90°C as per requirement
