Sheathed Control Flexible Cable

Sheathed Control Flexible Cable photo-1
US$ 0.9 - 99 MOQ: 2000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Bendakang
Model Number:
CY screened flexible control cable
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name Bendakang
Model Number CY screened flexible control cable
Application Industrial
Conductor Material Copper
Jacket PVC
Insulation Material PVC

sheathed control flexible cable

A continental style flexible power control cable, commonly known as ’CY’ type. The fine stranding of the cores combined with the tinned copper braid produces a cable with the characteristics of a flexible mains cable but with the screening properties of a screened signal cable. This makes the cable ideal for applications such as automated and robotic equipment where screening is required and the equipment may be subjected to vibration or movement.
Conductors: Annealed copper.
Sheath: PVC.
Braid: Tinned annealed copper.
Outer sheath: Grey PVC.

Core colours:

  • 3-core: Blue, Brown, Green/Yellow
    4-core: Grey, Brown, Black, Green/Yellow (See note)
    5-core: Blue, Brown, Black, Grey, Green/Yellow
    7-core: Green/Yellow + 6 numbered

Manufactured to VDE 2050 standard

CSA 0.75mm2 1mm2 1.5mm2 2.5mm2
Conductor size 24 / 0.2 32 / 0.2 30 / 0.25 50 / 0.25
Current rating (A) 6 10 16 20
Overall dia. (max.)
3-core 7.2 7.6 8.2 10.1
4-core 7.8 8.2 9.5 11.1
5-core - - 10.3 12.4
7-core - - 11.1 -
Voltage ratings:
between conductor and earth     300V
between conductors     500V
Current ratings:
For further details consult IEE Regulations 17th Edition
Temperature ratings:
Flexing -5°C to +70°C. stable -20°C to + 70°C
