YT-6600 Flexographic Printing Machine Plastic Bag Printing Machine

YT-6600 Flexographic Printing Machine Plastic Bag Printing Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other, Flexography
Place of Origin:
China
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Plate Type Other, Flexography
Place of Origin China
Brand Name HuaNa
Model Number YT-6600
Usage Paper Printer, Card Printer, Other, Paper Printer, Card Printer, Plastic Printer
Automatic Grade Other, Automatic, Automatic
Voltage 380V 50Hz
Dimensions(L*W*H) 4800X1600X2400mm
Certification CE BV ISO9001:2008
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Plastic Bag Printing Machine
2.high speed
3.CE standard

YT-6600Plastic Bag Printing Machine



Description:

Introduce sensitization resin as flexible printing plate, suitable for printing such packing materials as polyethylene, polypropylene bag, cellophane and roll paper, etc. It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.

The printing cylinder is installed on one side which can be load in one container without separating.

This machine can be installed with Reverse printing device to meet customers' requirement of printing both side of substrate.





Feature:

1. Easy operation, flexible starting, accurate color register.

2. The meter counter can set printing quantity according to the requirements. Stop the machine automatically at the quantity or when the material is cut off.

3. Pneumatic printing cylinder lift and lower, it will stir the printing ink automatically after lifting.

4. The printing ink is spread by the anilox cylinder with even ink color.

5. Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.

6.360°continuous and adjustable longitudinal register device.

7. The frequency control of motor speed adapts to different printing speeds.

8. There are Jogging/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.

9. Magnetic powder brake for unwinding tension control,magnetic powder clutch for rewinding tension control.

10. With double unwinding &rewinding shaft



Main Technical Parameter:

TYPE

YT-6600-6color-flexo press

Max.width of material

600mm

Max.printing width

560mm

Max.printing speed

50m/min

Max.Mechanical speed

60m/min

Max. unwinding and rewinding diameter of Roll Material

Φ450mm

Internal Diameter of Roll Core

φ76mm

Cylinder diameter

φ400mm(Customer can order other sizes)

Rang of Repeat Printing Length

191-914mm

Plate Thickness(Bothside adhesive included)

2.38mm

Accuracy of Registration

Vertical

+/-0.25mm

Horizontal

Tension control range

0-25kg

Heating Power

9kw

Main motor power

15kw

Total power

23kw

Weight of Machine(film packing dimension)

3500kg

Machine dimension(L x W x H)(film packing dimension)

L4300×W1700×H2950mm

Wooden packing Dimension

L4450×W1850×H3100mm





YT-6600 Flexographic Printing Machine Plastic Bag Printing MachineYT-6600 Flexographic Printing Machine Plastic Bag Printing Machine
YT-6600 Flexographic Printing Machine Plastic Bag Printing Machine

 YT-6600 Flexographic Printing Machine Plastic Bag Printing Machine
