Specifications
high temperature wire silcone rubber wire1 high quality,low price
2 professional OEM manufature
3 UL,SGS,ISO,CCC,VDE
Specifications
1.Rated Voltage:600V
2.Rated temperature:-60°C~+150°C
3.Conductor: nickel-coated, tin-coated and silver-coated copper wire
4.Insulator: silicone rubber
5.Applicable for electron, electrical household appliance, lamps and lanterns, and the internal high temperature environment of combustion equipment
Product dimensions
|
AWG NO. |
Spec. mm² |
Conductor |
Insulation |
Wire dimeter |
Max resistance 20°C (Ω/KM) |
||||
|
Structure No./mm |
Diameter mm |
Nominal Thickness mm |
Min Thickness mm |
Nominal mm |
Tolerance mm |
||||
18 |
0.823 |
7/0.39 |
1.20 |
0.80 |
0.72 |
2.80 |
±0.15 |
21.8 |
|
16/0.26 | |||||||||
16 |
1.31 |
7/0.49 |
1.47 |
0.80 |
0.72 |
3.10 |
±0.15 |
13.7 |
|
26/0.26 |
1.55 |
0.80 |
0.72 |
3.15 |
|||||
14 |
2.08 |
7/0.62 41/0.254 |
1.90 |
0.80 |
0.72 |
3.50 |
±0.20 |
8.62 |
|
12 |
3.31 |
19/0.49 43/0.32 |
2.50 |
0.80 |
0.72 |
4.10 |
±0.20 |
5.38 |
|
18 |
0.823 |
1/1.03 |
1.03 |
0.80 |
0.72 |
2.65 |
±0.15 |
21.4 |
|
16 |
1.31 |
1/1.30 |
1.30 |
0.80 |
0.72 |
2.90 |
±0.15 |
13.5 |
|
Production Line
Product show
Certificates
Quality Control & Test Instruments
Factory Overlook
