Specifications
High-voltage wire1. High quality, low price,quick delivery
2. Professional OEM manufature
3. ISO,CCC,UL,VDE
JGG-3KV Silicone Rubber Insulation High-voltage Electrical Motor Leading Wire
Product features:
Rated voltage: 3000V
Rated temperature: -60°c~200°c
Conductor: tin-coated copper wire
Insulator: Silicone Rubber
|
Spec. mm |
Conductor |
Insulation |
Wire dimeter |
Max resistance 20°C (Ω/KM) |
|||
Structure No/mm |
Diameter mm |
Nominal Thickness mm |
Min Thickness mm |
Nominal mm |
Tolerance mm |
||
0.75 |
24/0.20 |
1.15 |
2.0 |
1.7 |
5.15 |
±0.20 |
26.7 |
1.0 |
32/0.20 |
1.34 |
2.0 |
1.7 |
5.35 |
±0.20 |
20.0 |
1.5 |
30/0.25 |
1.60 |
2.2 |
1.88 |
6.0 |
±0.25 |
13.7 |
2.0 |
41/0.25 |
1.90 |
2.2 |
1.88 |
6.3 |
±0.25 |
9.9 |
2.5 |
49/0.25 |
2.00 |
2.4 |
2.06 |
6.8 |
±0.25 |
8.21 |
4.0 |
56/0.30 |
2.70 |
2.4 |
2.06 |
7.5 |
±0.25 |
5.09 |
6.0 |
84/0.30 |
3.30 |
2.6 |
2.24 |
8.5 |
±0.25 |
3.39 |
10.0 |
84/0.40 |
4.60 |
2.6 |
2.24 |
9.8 |
±0.25 |
1.95 |
16.0 |
126/0.40 |
5.80 |
2.8 |
2.42 |
11.4 |
±0.25 |
1.24 |
25.0 |
196/0.40 |
7.30 |
2.8 |
2.42 |
12.9 |
±0.30 |
0.795 |
35.0 |
276/0.40 |
8.60 |
2.8 |
2.42 |
14.2 |
±0.30 |
0.565 |
50.0 |
396/0.40 |
10.7 |
3.0 |
2.6 |
16.7 |
±0.30 |
0.393 |
70.0 |
360/0.50 |
12.4 |
3.0 |
2.6 |
18.4 |
±0.30 |
0.277 |
95.0 |
475/0.50 |
14.5 |
3.2 |
2.78 |
20.9 |
±0.40 |
0.21 |
120.0 |
608/0.50 |
16.0 |
3.2 |
2.78 |
22.4 |
±0.40 |
0.164 |
150.0 |
756/0.50 |
18.0 |
3.5 |
3.05 |
25.0 |
±0.60 |
0.132 |
185.0 |
925/0.50 |
20.0 |
3.5 |
3.05 |
27.0 |
+0.60
|
0.108 |
240.0 |
1221/0.50 |
23.0 |
3.5 |
3.05 |
30.0 |
+0.60
|
0.0817 |
