Specifications
High Speed Gravure Printing Machine1. Printing color: 1-12
2. Width: customer build
3. Speed: 180m/min
------------------------------------------------------------------------------------------------------------------------------
multi color rotogravure printing machine/3d printer
------------------------------------------------------------------------------------------------------------------------------
USE:
PVDC 35-60um PET 12-60um
OPP 20-60um BOPP 20-60um
PE 30-100um NY 12-50um
CPP 20-60um Cmbination film 15-60um
------------------------------------------------------------------------------------------------------------------------------
Feature:
1. Load/Unload: AIr shaft
2. Tension control: magnetic powder brake
3. Install printing plate with shaft
4. Adjustable three position scraper easy to adjust scraper angle
5. Intelligent continuous constant temperature control.
6. Air insert closed oven
7. Electricity heating
8. With tornado layout, drying from inner to outer, do not have blister phenomenon
9. Single unit auto constant temperature control, good for every color printing
------------------------------------------------------------------------------------------------------------------------------
Main parameter:
Direction |
From unwind to rewind |
Max printing width |
1300mm |
Max machine speed |
100m/min |
Max printing speed |
10-80m/min |
Precision of register |
Vertical ±0.15mm Manual Horizontal ±0.15mm Manual |
Unwinding diameter |
Φ600mm |
Rewinding diameter |
Φ600mm |
Tension |
3-30Kg |
Precision of tension |
±0.5Kg |
Scraper swing capacity |
±5mm |
Heat way |
Electricity |
Main power |
65kw |
Dimensions |
8000x1970x2320mm |
