High Speed 8 Colors Roll Papers Gravure Printing Machine

Name: High Speed 8 Colors Roll Papers Gravure Printing Machine
Brand: RUITAI
SKU: 117936197

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Zhejiang, China

Brand Name:

RUITAI

Ruian Xintai Printing Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo Port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Zhejiang, China

Brand Name RUITAI

Model Number YAD-T

Usage Other, Film printer

Automatic Grade Automatic

Gross Power 210kw

------------------------------------------------------------------------------------------------------------------------------

High Speed 8 Colors roll papers gravure Printing Machine

------------------------------------------------------------------------------------------------------------------------------

Feature:

1. Independent tower type double arm duplex position slewing and wall rack combination

2. Auto alarm change materials, new material auto driving at the same speed with main machine

3. High speed non-stop change material, save time

4. Install printing cylinder without shaft

5. Independent heating system in every color unit

6. Intelligent continuous constant temperature control.

7. Wind insert closed oven

------------------------------------------------------------------------------------------------------------------------------

Printing material

80-280gsm paper

Main parameter
Direction	From left to right
Printing color	8 color
Max width	850mm
Max machine speed	100m/min(Φ200mm)
Max printing speed	80m/min(Φ200mm)
Diameter of printing cylinder	Φ120mm-Φ300mm
Precision of register	Lengthwise ±0.2mm (Auto register tracking)
Precision of register	Cross direction ±0.2mm (Manual control)
Unwinding diameter	Φ1500mm
Paper collect way	Web material (Printing surface outside)
Shaft	Air shaft
Paper core diameter	3" or 6"
Tension	20-60Kg
Precision of tension	±0.5Kg
Air supply	0.8Mpa
Pressing force	2500kg
Doctor blade swing capacity	±5mm
Heat way	Electricity / Steam (Customer build)
Water cooling pressure	2-3kg/cm2, 18-20°C
Main motor power	22kw
Main power	210kw (Electric heating) 130kw (Steam heating)
