Embedded installation front panel IP65 waterproof 19 inch open frame monitor
1. Robust and durable all-metal enclosure, dustproof and shockproof.
2. Industrial LCD panel, wide viewing angle, high nits, true color.
3. 4 wire resistive touch panel , high sensitive and fast-response.
4. High performance mainboard, 7x24 continuous operation.
5. Adopt HDMI 1.4 Digital decoding scheme, strong compatibility.
Model:SL19O | |
LCD panel | |
Panel size |
19" |
Resolution |
1280*1024 ( 1440*900 optional ) |
Aspect ratio |
4:3 ( 16:9 optional ) |
Support Color |
16.7M colors |
Brightness (cd/m²) |
350+ |
Contrast ratio |
1000:1 |
View angle |
80°/80°/75°/85° (R/L/U/D) |
Touch panel | |
Touchscreen Type |
4 wire resistive touch |
Touch Interface |
USB (RS232 optional) |
Touch response time |
<8ms |
Luminousness |
75-85% |
Surface Hardness |
3H |
Working Life |
>5 million times |
Touch options |
( 5 wires resistive touch, IR ,SAW touch optional) |
Singal Ports | |
VGA |
1×VGA |
HDMI |
1×HDMI |
DVI |
1×DVI |
AV |
optional |
Audio in/out |
optional |
OSD | |
OSD control |
Brightness, contrast ratio, auto adjustment, H/V position, language select etc. |
Support languages |
English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese etc. |
Support OS |
Windows XP , Windows /7/8/10 , Linux, Mac OS X, Android ect. |
Power Supply | |
External Power Supply |
AC 100 - 240V |
Working voltage |
DC 12V |
Power consumption |
≤25W |
Enclosure | |
Appearance |
Flat panel |
Material |
High strength cold rolled steel |
Color |
Black, white, Silver , color can be customized |
VESA mounting |
100×100mm |
Degree Protection |
IP65 optional |
Operating Environment | |
Temperature Range |
operating: -10 to 60°C, storage :-20 to 80°C |
Relative humidity |
operating: 10% to 90% , storage :5% to 90% |
Packing Details | |
Net weight |
4.5kg |
Gross weight |
6kg |
Product Dimension |
46.78×29.98×4.9 cm |
Packing size |
55.6×42.2×13.6 cm |
Accessories |
Power adapter, HDMI /VGA/DVI cable, USB touch cable, touch pen |
Other | |
Mounting (options) |
1) provide wall brackets for wall-mounting, VESA 100×100mm |
2) provide stable metal holder to support the monitor | |
Certification |
CE, FCC, ROHS |
Warranty |
1 year warranty and 3 years free maintenance |
