Touchscreen industrial 15 inch touch all-in-one PC for process control

Model:SC15W

PC

CPU

Intel® Celeron 1037  1.8GHz , dual core

Chipset

Intel NM70

Memory

2G  DDR3,  ( Max. 8G)

Hard Drive Capacity

32G SSD or 320G HDD

Hard Drive Optional

SSD:  16GB,32GB,64GB,128GB,160GB

HDD: 160GB,320GB,500GB,1TB

Graphics

CPU Integrated graphics HD Graphics and support 1080p HD photo quality

Audio

Realtek ALC662, High Definition Audio (HD), Line in, Line out

Network

1×Realtek RTL 8111E Gigabit Ethernet controller

Wireless Network

WIFI optional

I/O Interface

2×USB2.0 ,  2×USB3.0,   2 x COM RS232

1×VGA/HDMI/RJ45/Audio OUT/MIC IN/POWER DC

Opetation System

Preinstall test version Windows 7

LCD panel

Panel size

15"

Resolution

1024*768

Aspect ratio

4:3

 Support Color

16.7M colors

Brightness (cd/m²)

400+

Response time

10ms

Contrast ratio

700:1

View angle

70°/70°/65°/60° (R/L/U/D)

Touch panel

Touchscreen Type

4 wire resisitve touch

Touch Interface

USB   (RS232 optional)

Touch response time

<8ms

Luminousness

75-85%

Surface Hardness

3H

Working life

>5 million times

Touch options

( 5 wires resistive touch,  IR ,SAW touch optional)

Power Supply

External Power Supply

AC 100 - 240V

Working voltage

DC 12V

Power consumption

≤30W

Enclosure

Material

High strength cold rolled steel

Color

Black, white, Silver , color can be customized

VESA mounting

100×100mm

Operating Environment

Temperature Range

operating: -25 to 75°C,  storage :-30 to 80°C

Relative humidity

5%~95% @ 40° C, non-condensing

Vibration

5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis

Packing Details

Net weight

3.3kg

Gross weight

5kg

Product Dimension

33.2×26.1×5.25 cm

Packing size

42.0×35.0×16.0 cm

Accessories

Power adapter, USB touch CD drive, touch pen,  wall mounting bracket (optional)

Other

Mounting (options)

1) provide wall brackets for wall-mounting, VESA 100×100mm

2) provide stable metal holder  to support the monitor

Certification

CE, FCC, ROHS

Warranty

1 year warranty and 3 years free maintenance
