Specifications
1, 55" Multitouch IR Touch Open Frame Monitor2, USB,RS232,VGA.HDMI input
Model |
TM-5558-G413U8 |
Description |
55” TFT Open Frame TouchMonitor |
Case/Bezel Color |
Black |
Touchmonitor Performance |
Standard |
Display Type |
16:9 Ratio52” Active Matrix TFT LCD |
Active Display Area |
1214*685mm |
Native Resolution |
1920 x 1080 @ 60Hz |
Synchronization Range |
135 KHz horizontal, 120 Hz Vertical |
Pixel Response Time Rise + Fall (Typically) |
6.5 m s |
Plug and Play |
VESA DDC 1/2B |
On Screen Display (OSD) |
Remote OSD with 1.2m Cable |
Colors |
16.7M colors |
Brightness (From Centre, CR>=5) |
500 cd/m² |
Contrast Ratio Typically |
8000:1(active) |
Viewing Angle Horizontal (left/right) |
178º(89º/89º) |
Viewing Angle Vertical (up/down) |
178º(89º/89º) |
Backlight Lamp life |
50000 Hrs to ½ brightness |
Input Video Format |
Analog (VGA), S-Video, YPbPr&YCbCr, HDMI |
Touch Technology |
Infrared Multitouh IP65 |
Touchscreen Interface |
USB |
Touch Response Time Serial/USB |
15ms |
Touch Sensitivity |
Fixed |
Monitor Dimensions |
1369.3*872.2*150mm |
Carton Dimensions |
TBD |
Weight (approximately) |
TBD |
Mounting Options |
Rear Mount, VESA 400×200 |
Power Supply |
External: 100-240V, 50-60 Hz |
Power Consumption |
350 Watts maximum |
Temperature Range |
Operating: 0°C~35°C, Storage: -10°C~50°C |
Relative Humidity |
Operating:10%-90%, Storage 10%-90% Non Condensing |
Warranty* |
1 years |
Agency Approvals |
RoHS, CE, FCC |
LeadingTouch 55" Open Frame IP65 Multitouch Touch Monitor TM-5558-G413U8
Open Frame
Slim profile with unique narrow border
Multiple mounting options
Open-Frame VESA mounting option and removable wing bracket for VESA
Detachable cables for easy cable hamessing
Single power sepply for all optional devices
Multingual and detachable on screen display (OSD)
Combo Serial and USB touch interface
Super-sensitive, drift-free, precise touch with no overlay
Long-lasting product cycle
Worldwide agency approvals
Application
LeadingTouch Open Frame LCD's touchmonitors are designed for easy integration into kiosk, gaming machine, industrial enclosure and other installations where compact, touch-integrated display are preferred touchscreen.
This 55 inch Open Frame Touch Monitor are designed for space saving and easy mounting integrations. The Open Frame configuration along with optional side mounting brackets would enable you to easily customize into kiosks, cabinets, in-wall as well as other enclosures.
