Specifications
1, 42inch Multitouch touch monitor2, Infrared touch technology
3, USB
4, VGA,DVI and HDMI
5, resolution 1920 x 1080
TM-4258 Multitouch Infrared Touch Screen LCD touchmonitor with a removeble stable tilt base and IP65 Infrared touch screens. These LCD monitors provide you with premium quality in optical resolution, durability and stability. Built with high quality ABS plastic frame along with unique designed and integrated watertight IP65 rated plastic bezel, this unit becomes completely dust and water proof. This is an ideal solution for harsh environments that are humid, dust and water proof. These could also withstand various public and weather conditions.
Model |
TM-4258 |
Description |
42" Open Frame Infrared(IR) Touch Monitor |
Case/Bezel Color |
Black |
Display |
16:9 Active Matrix TFT LCD |
Optimal (native) Resolution |
1920 × 1080@60Hz |
Sychronization Range |
Horizontal: 60 - 73 KHz, Vertical: 47 - 63 Hz |
Useful Screen Area |
934 x 527mm |
Colors |
16.7 M |
Brightness |
350 cd/m2 |
Pixel Pitch |
0.4845 × 0.4845mm |
Response Time |
6.5ms (Typically) |
Contrast Ratio |
3000:1 (Typical) |
Viewing Angle(CR≥10) |
Horizontal: ±89° or 178° total |
Vertical: ±89° or 178° total | |
Backlight Lamp Life |
50000 hrs |
Input Video Format |
VGA / DVI / HDMI |
Input Video Signal Connector |
VGA/ DVI / HDMI |
On Screen Display(OSD) |
Controls (back): ON/OFF,MENU,LEFT,RIGHT,SEL,AUTO |
Touch Technology |
Leadingtouch Infrared(IR),Single-Touch or Dual-Touch |
Touch Interface |
RS232 or USB or Dual RS232&USB interface |
Mounting Options |
VESA Mount (200mm × 400mm) , Side Mount or Front Mount with optional bracket |
Power Supply |
100-240VAC, 50-60Hz |
Power Consumption |
157W Max |
Temperature Range |
Operating: 0°C to 50°C; Storage: -20°C to 60°C |
Humidity Range (no condensing) |
Operating: 20%-80%; Storage: 10%-90% |
Dimension |
Touchmonitor 1007 x 600 x 122.5mm, net weight 31.4kg |
Box after packing : 1130 x 310 x 850mm weight 37.6kg | |
Warranty |
1 year |
Agency Approvals |
FCC, CE, RoHS |
