Performance and Characteristics
This sheet cutting machines(paper cutting machinery, paper cutter) is suitable for cutting big rolling packaging materials such as paper, pape-plastic, muliticolor laminated material, etc. It adopts servo motor( or stepless motor) for controlling constant -length cutting. It adopts pneumatic, photoelectric sensor for controlling transmission system, with photo, electric, gas together. It has the function of easy operation, high precision, good stability, low noise.( Pneumatic auto loading device is optional). This machine has the functions of the frequency converter timing device, automatic counting, stop working by alarm and tension adjustment by magnetic powder or manual with friction unit.
Main Technical Parameters
| Model | HQJ-800B | HQJ-1100B | HQJ-1300B |
| Max.diameter of material | Φ1400mm | Φ1400mm | Φ1400mm |
| Max.width of cutting | 800mm | 1100mm | 1300mm |
| Length of cutting | 20-1200mm | 20-1200mm | 20-1200mm |
| Precision of fixed length | ±0.2mm | ±0.2mm | ±0.2mm |
| Speed | 10-140times/min | 10-140times/min | 10-140times/min |
| Total power | 4kw | 4kw | 5kw |
| Weight(approx.) | 1200kg | 1700kg | 2100kg |
| Overall dimension(LΧWΧH) | 2200Χ1400Χ1200(mm) | 2200Χ1700Χ1200(mm) | 2200Χ1900Χ1200(mm) |
Design and specifications are subject to change without notice
