Pipe Fabrication Automatic Welding Machine (FCAW/GMAW

Name: Pipe Fabrication Automatic Welding Machine (FCAW/GMAW
Brand: QIANSHAN/QSPT
SKU: 117772089
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

QIANSHAN/QSPT

Model Number:

PPAWM-16Aa/24Aa/32Aa

Shanghai Qianshan Piping Technology Co., Ltd. (QSPT)

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name QIANSHAN/QSPT

Model Number PPAWM-16Aa/24Aa/32Aa

Wire Feeding Speed AS PER REQUIREMENT

Dimensions AS PER REQUIREMENT

Usage BUTT WELDING

Specifications

1.HIGH PRODUCTION CAPACITY & GOOD QUALITY; 2.IMPROVE WORK EFFICIENCY;3.REDUCE MANPOWER INPUT;4.AUTOMATION LEVEL HIGH;
5.SAVE

Pipe Fabrication Automatic Welding Machine (FCAW/GMAW)

Model: PPAWM-16Aa/24Aa/32Aa

Performance features

On-line Performance: Excellent (Designed completely as per the on-line equipment of the production line)
Application: extremely broad (pipe and cover welding of various structures in various industries).
Operability: Good (applicable and easy to operate even if you are a new user)
Surface finishing: Excellent (the welding gun will be positioned in the optimum position always)
Welding qualification rate: 98% min (without re-working for the skilled operator).
Driving Reliability: Good (driven by frictional force, however, it is required to set essential balance weight to offset large bending moment caused by elbows for large diameter pipe, or providing a chain tensioner to improve the reliability of the driving).

Technical parameters

Welding line applicable: various butt welding lines of spool pieces such as pipe-pipe, pipe-elbow, pipe-flange, flange-flange and flange-elbow, etc (a fake pipe transition connection shall be applied if necessary).
Driving System: driven by two line rubber roller and reducer
Clamping system: clamping arm move up & down electrically and clamps by screw with telescope boom.
Bracket System: Separate type of trolley matching for welding equipments, which may be adjusted along the track according to the length of the pipe
Counterweight System: no Counterweight
Speed regulation Mode: VF stepless speed control system
Adjustment Mode: electric cross regulator
Oscillating system: a product of our patented technology, step motor driving and digital displaying oscillating width adjusting .
Control system: a product of our patented technology, PLC control
Welding Power: our OEM products which are famous in China (or as per customers’ demands)

Performance features

On-line Performance: Excellent (Designed completely as per the on-line equipment of the production line)
Application: extremely broad (pipe and cover welding of various structures in various industries).
Operability: Good (applicable and easy to operate even if you are a new user)
Surface finishing: Excellent (the welding gun will be positioned in the optimum position always)
Welding qualification rate: 98% min (without re-working for the skilled operator).
Driving Reliability: Good (driven by frictional force, however, it is required to set essential balance weight to offset large bending moment caused by elbows for large diameter pipe, or providing a chain tensioner to improve the reliability of the driving).

Technical parameters

Welding line applicable: various butt welding lines of spool pieces such as pipe-pipe, pipe-elbow, pipe-flange, flange-flange and flange-elbow, etc (a fake pipe transition connection shall be applied if necessary).
Driving System: driven by two line rubber roller and reducer
Clamping system: clamping arm move up & down electrically and clamps by screw with telescope boom.
Bracket System: Separate type of trolley matching for welding equipments, which may be adjusted along the track according to the length of the pipe
Counterweight System: no Counterweight
Speed regulation Mode: VF stepless speed control system
Adjustment Mode: electric cross regulator
Oscillating system: a product of our patented technology, step motor driving and digital displaying oscillating width adjusting .
Control system: a product of our patented technology, PLC control
Welding Power: our OEM products which are famous in China (or as per customers’ demands)

Technical Description	Standard Type
Welding Capacity:	250-350 inch/day(4 times higher than the manual welding)
Pipe diameter applicable:	DN50-400/DN50~600/DN200-800
Pipe wall thickness applicable:	3~30mm
Materials applicable:	carbon steel, alloy steel, stainless steel and cryogenic steel
Welding procedure:	FCAW/GMAW (can do root pass, filling, & final welding)
