Help CenterSlip on Flange Automatic Welding Machine (FCAW/GMAW)
Related Products
-
PIPE PREFABRICATION AUTOMATIC WELDING MACHINE (FCAW/GMAW)NegotiableMOQ: 1 Set -
PIPING PREFABRICATION AUTOMATIC WELDING MACHINE (SAW)NegotiableMOQ: 1 Set
-
Piping All~position Automatic Welding Machine (GTAW)US$ 300,000 - 400,000MOQ: 1 Set
-
Portable Piping Automatic Welding Machine (FCAW/GMAW)US$ 80,000 - 110,000MOQ: 1 Set
-
Slip~on Flange Automatic Welding Machine (FCAW/GMAW)US$ 250,000 - 500,000MOQ: 1 Set
Specifications
1.HIGH PRODUCTION CAPACITY & GOOD QUALITY; 2.IMPROVE WORK EFFICIENCY;3.REDUCE MANPOWER INPUT;4.AUTOMATION LEVEL HIGH;5.SAVE
Slip-on Flange Automatic Welding Machine (FCAW/GMAW)
Model: PPAWM-24Da/32Da
Performance features
l Online-performance: Design not for the working of production line
l Application: Slip~on Flange for the welding line of the internal and external incidence angle
l Operability: very good (applicable and easy to operate even if you are a new user within a short period of time)
l Surface Forming: Excellent (the welding gun will always be positioned in the optimum position)
l Driving Reliability: good
Technical parameters
l Welds applicable: welding line of flange-pipe
l Machine head system: one welding head with two welding guns at one end/two welding heads with four welding guns both at two ends .
l Driving system: driven the motor of active idler wheel frame
l Clamping system: clamped by chain or contact roller
l Bracket system: two sets of active idler wheel frame are to be set and it is adjustable according to the pipe length along the track.
l Counterweight System: Nil
l Speed-Regulation Mode:VF stepless speed control system
l Adjustment Mode: electric cross regulator
l Swaying system: a product of our patented technology, driven by step motor and oscillating adjusting with digital display.
l Control system: a product of our patented technology, PLC control.
l Welding Procedure: FCAW/GMAW(or as per request)
l Welding Power: our OEM products which are famous in China (or as per customers’ demands)
| Technical Description | Standard Type |
| Welding Capacity: | 250~280inch/day (which is 4 times higher than the manual welding) |
| Welding compliance rate: | 98% min (without re-working for the skilled operator) |
| Pipe diameter applicable: | DN100-600/ DN100-800 |
| Pipe wall thickness applicable: | 3~30mm |
| Materials applicable: | carbon steel, alloy steel, stainless steel and cryogenic steel etc. |
Welcome to visiting our factory or project site at any time in Shanghai City, P.R.China; For more detail information please contact us. Thank you !
Photos:
Slip-on Flange Automatic Welding Machine (FCAW/GMAW)
Model: PPAWM-24Da/32Da
Performance features
l Online-performance: Design not for the working of production line
l Application: Slip~on Flange for the welding line of the internal and external incidence angle
l Operability: very good (applicable and easy to operate even if you are a new user within a short period of time)
l Surface Forming: Excellent (the welding gun will always be positioned in the optimum position)
l Driving Reliability: good
Technical parameters
l Welds applicable: welding line of flange-pipe
l Machine head system: one welding head with two welding guns at one end/two welding heads with four welding guns both at two ends .
l Driving system: driven the motor of active idler wheel frame
l Clamping system: clamped by chain or contact roller
l Bracket system: two sets of active idler wheel frame are to be set and it is adjustable according to the pipe length along the track.
l Counterweight System: Nil
l Speed-Regulation Mode:VF stepless speed control system
l Adjustment Mode: electric cross regulator
l Swaying system: a product of our patented technology, driven by step motor and oscillating adjusting with digital display.
l Control system: a product of our patented technology, PLC control.
l Welding Procedure: FCAW/GMAW(or as per request)
l Welding Power: our OEM products which are famous in China (or as per customers’ demands)
| Technical Description | Standard Type |
| Welding Capacity: | 250~280inch/day (which is 4 times higher than the manual welding) |
| Welding compliance rate: | 98% min (without re-working for the skilled operator) |
| Pipe diameter applicable: | DN100-600/ DN100-800 |
| Pipe wall thickness applicable: | 3~30mm |
| Materials applicable: | carbon steel, alloy steel, stainless steel and cryogenic steel etc. |
Welcome to visiting our factory or project site at any time in Shanghai City, P.R.China; For more detail information please contact us. Thank you !
Photos:
