2013 New Mining Copper Ore Flotation Machine,separator Machine by Zhongde Brand

2013 New Mining Copper Ore Flotation Machine,separator Machine by Zhongde Brand thumbnail-1
2013 New Mining Copper Ore Flotation Machine,separator Machine by Zhongde Brand photo-1
US$ 1,693 - 1,935 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Flotation Separator
Place of Origin:
Henan, China
Contact Supplier Request Quote Chat Now
Luoyang Zhongde Heavy Industries Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin qingdao port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Flotation Separator
Place of Origin Henan, China
Brand Name ZHONGDE
Model Number BF-O.65
Power(W) 3.0KW
Dimension(L*W*H) 0.85X0.95X0.90m
Certification ISO, BV,CE certificate
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.ISO9001:2008
2.Big air inlet amount 3.
3.low energy consumption
4.Rational ore pulp circulation

Characteristics of BF flotation Machine:



BF flotation machine is improved on the basis of SF flotation machine.

1. The impeller consists of closed double section cones, which can produce strong down-circulation;

2. Big air inlet amount, low energy consumption;

3. Each trough has the function of air suction, ore pulp suction and flotation, it can make a flotation circuit itself, with no auxiliary equipments. The horizontal configuration makes it easy to change process;

4. Rational ore pulp circulation reduces coarse sand sediment;

5. There are automatic and electric control devices of ore pulp level, which makes easy adjustment.



Technical parameters:



Model

Effective     volume           ( m3 )

Inside dimensions             (L×W×H)     ( m )

Air suction amount (m3/min)

Power             (KW)

Motor model

Processing capacity (m3/min)

Single trough weight       ( kg )




BF-0.37

0.37

0.74×0.74×0.75

0.9~1.05

1.5

Y90L-4

0.2~0.4

470



BF-0.65

0.65

0.85×0.95×0.90

0.9~1.10

3.0

Y132S-6

0.3~0.7

932



BF-1.2

1.2

1.05×1.15×1.10

1.0~1.10

5.5     4.0

Y132M2-6 Y132M1-6

0.6~1.2

1370



BF-2.0

2

1.40×1.45×1.12

1.0~1.10

7.5

Y160M-6

1.0~2.0

1750



BF-2.8

2.8

1.65×1.65×1.15

0.9~1.10

11

Y180L-8

1.4~3.0

2130



BF-4.0

4

1.9×2.1×1.2

0.9~1.10

15

Y200L-8

2~4

2585



BF-6.0

6

2.2×2.35×1.3

0.9~1.10

18.5

Y225S-8

3~6

3300



BF-8.0

8

2.25×2.85×1.4

0.9~1.10

22       30

Y225M-8 Y250M-8

4~8

4130



BF-10

10

2.25×2.85×1.7

0.9~1.10

22       30

Y225M-8 Y250M-8

5~10

4660



BF-16

16

2.85×3.8×1.7

0.9~1.10

37       45

Y280S-8 Y280M-8

8~16

8320



BF-20

20

2.85×3.8×2.0

0.9~1.10

37       45

Y280S-8 Y280M-8

10~20

8670



BF-24

24

3.15×4.15×2.0

0.9~1.10

45

Y280M-8

12~24

8970



 pictures of product:

2013 new mining copper ore flotation machine,separator machine by Zhongde brand



2013 new mining copper ore flotation machine,separator machine by Zhongde brand
