Home > Manufacturing & Processing Machinery > Mining Machinery > Mineral Separator > Spiral Classifier for Mineral Pocessing/mineral Screw Classifier

Spiral Classifier for Mineral Pocessing/mineral Screw Classifier

Name: Spiral Classifier for Mineral Pocessing/mineral Screw Classifier
Brand: ZHONGDE
SKU: 117606377

Spiral Classifier for Mineral Pocessing/mineral Screw Classifier thumbnail-1

Spiral Classifier for Mineral Pocessing/mineral Screw Classifier photo-1

US$ 5,806 - 6,774 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Sprial Separator

Place of Origin:

Henan, China

Contact Supplier Request Quote Chat Now

Luoyang Zhongde Heavy Industries Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

tianjin qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Sprial Separator

Place of Origin Henan, China

Brand Name ZHONGDE

Model Number FG-750X5500

Dimension(L*W*H) 6720x980x1820mm

Certification ISO,BV,CE certificate

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Hot sale in Africa, East Asia,etc
2.Spral diameter:750mm
3.Spiral speed:6-10r/min
4.Negotiable price
5.Mix strongly

Working Principle:

If there are two spiral axles in the chute, all of the spiral blades rotate outwards when the machine is viewed from the top. The slurry, fed from the flank of the chute, form classification of sedimentation at the bottom of the chute. Coarse particles dip into the bottom of the chute, and then they will be pushed to the top by the spiral and discharged. During the transportation process, the coarse particles dehydrate themselves. The fine particles, which do not have enough time to dip into the bottom of the chute, are carried by the ore pulp flow through the surface and discharged from the overflow weir. There is lifting equipment on the upper beam of the frame, which is used to adjust the distance between the spiral blades and the chute bottom and raise the spiral axle when the machine stops working, in case that the ores deposit and bury the spiral blades to damage the axles and blades when the machine starts working again.

Types:

According to the height of the surface of the liquid classification, the machines can be divided into high weir type and immersed weir type. The overflow weir of the high weir type spiral classifier is higher than the center of the spiral axle at the bottom and lower than the top of the spiral blades. As the surface of the liquid classification is not very long, the liquid surface can feel the mixing of the spiral blades, and then this kind of machine can be used for the classification of coarse particles, whose classification granule is more than 0.15MM. The whole spiral blades of the immersed weir type are immersed in the flooding level, the area of the classification is large and stable, which is suitable for the classification of the fine particles, the classification granule of which is less than 0.15mm. It has high productivity. Besides, there is one kind of low weir type of spiral classifier, whose surface of the liquid classification is lower than the spiral bearing. The area of the liquid surface is small,but the machine can mix strongly. It is mainly used in the washing of the ores with mud.

Advantages are simple structure, reliable working condition and convenient operation.

Technical parameters:

Model	Spiral diameter (mm)	Spiral rotation speed (r/min)	Processing Capacity(t/d)		Trough length (mm ≤)	Motor power ( KW )		Dimensions (mm ≤)
Model	Spiral diameter (mm)	Spiral rotation speed (r/min)	Sand-return	Overflow	Trough length (mm ≤)	For driving	For lifting	Length	Width	Height
FG-5	500	8-12.5	135-210	32	4500	1.1	----	5430	680	1480
FG-7	750	6-10	340-570	65	5500	3	----	6720	980	1820
FG-10	1000	5-8	675-1080	110	6500	5.5	----	7590	1240	2380
FC-10	1000	5-8	675-1080	85	8400	7.5	----	9600	1240	2680
FG-12	1200	4-6	1170-1870	155	6500	7.5	2.2	8180	1570	3110
FC-12			1170-1870	120	8400	7.5	2.2	10370	1540	3920
2FG-12			2340-3740	310	6500	15	4.4	8230	2790	3110
2Fc-12			2340-3740	240	8400	15	4.4	10370	2790	3920
FG-15	1500	4-6	1830-2740	235	8300	7.5	2.2	10410	1880	4080
FC-15			1830-2740	185	10500	7.5	2.2	12670	1820	4890
2FG-15			2280-5480	470	8300	15	4.4	10410	3390	4080
