DFHD-15 pipe laying underground drilling equipment Supplier's Choice

Name: DFHD-15 pipe laying underground drilling equipment Supplier's Choice
Brand: DEFY
Availability: InStock

FOB Price

USD $35,000 - $55,000 / Set

1 Set(Min.Order)

Supply Ability 50 Set / Sets per Month
Port Qingdao Ningbo
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other, HDD Drilling Rig
Power Type	Other, Diesel, diesel	Place of Origin	Henan, China
Brand Name	DEFY	Model Number	DFHD-15
Usage	Other, drilling	Voltage	Customized
Power(W)	66.2 KW	Dimension(LWH)	580020502380mm
Weight	6100kgs	Certification	BV,SGS certificate
Warranty	One year warranty excluding wearing parts	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Application:

DFHD-15 horizontal directional drilling rig is usually used when trenching or excavating is not practical. It is suitable for a variety of soil conditions and jobs including road, landscape and river crossings.

Advantages:

1> With low emission diesel engine, it is suitable for performance in city; direct fuel injection requires not preheat in winter.

2> The chassis and mast are high in rigidity and intensity, durable and reliable.

3>Equipped with hydraulic outriggers, easy to adjust the balance.

4>Mud pump is driven hydraulically with four-speed mechanical gear shift/stepless speed change.

5>Equipped individually of mud processing unit, adopting injection and recirculation storage procession method, labor saved.

6>With the rod, 60mm in diameter and 3000mm in length, the drilling tools are complete in matching accessories and could be produced in accordance with the requirement of clients unusually.

Power of Engine	66.2 KW(89HP) (2200r/min)
Max. Push capacity	75KN (16860 lbf)
Max. Pull capacity	150KN (33720 lbf)
Rated Torque	4200 N·M(3096 lbf·ft)
Hollow Spindle RPM	Lower 0-60r/min
Hollow Spindle RPM	High 0-120r/min
Feeding Stroke	3500 mm(137.8 inch)
Diameter of Guide Hole	80 mm(3.15 inch)
Drilling Angle	0°---20°
Pressure of hydraulic system	20-25Mpa(2901-3626 psi)
Traveling speed	2.5 km/h (8200 feet/h)
Structural Style	integrated with rubber crawler and mud pump
Dimension	580020502380 mm
Weight	6100 kg(13450 lb)

Detailed Image

World famous brand

The main hydraulic components are all famous brand from European and American suppliers, transfer case and reducer are adopted from well-known European factory, thus reliable operation of the rig is guaranteed.

Customer Visiting

Cambadia customers visited us in 11th, May and placed an order on 10th, June

Customer feedback

Packing & Delivery

Packaging
Size	580020502380 mm
Weight	6100kg
Packaging Details	20GP container

Our Service

Delivery time

Depends on the quantity, usually it is 7-10 working days after receiving the deposit.

Quality control

We have QC department, before shipping, goods will be strictly checked.

Tech support

- 24 hours * 7 days online pre & after sale service ;
- Factory site training or engineers go to overseas to train the workers ;
- Manual and DVD operation video.

Our Company

Zhengzhou Defy Mechanical & Electrical Equipment CO., Ltd. locates in High-tech zone of Zhengzhou City, China. Our factory dedicates to manufacturing drilling rigs since 1970s, more than 40 years experience of production and development make our product quality rank in the leading position at home and abroad.

Our drilling rigs are widely applicable for water well, farm irrigation, geological prospecting, small pile foundation, geothermal air-conditioner and so on, capable and functional. Our professional engineers and sales team, offering technical support and useful advices whenever you need.

Please contact Nora for best quotation:

Mobile/WhatsApp: 0086-15286806707
Email: nora @
Skype: nora-drillingrig @
