DFHD-68 Horizontal Directional Trenchless Earth Drilling Machine

DFHD-68 Horizontal Directional Trenchless Earth Drilling Machine thumbnail-1
DFHD-68 Horizontal Directional Trenchless Earth Drilling Machine thumbnail-2
DFHD-68 Horizontal Directional Trenchless Earth Drilling Machine thumbnail-3
DFHD-68 Horizontal Directional Trenchless Earth Drilling Machine thumbnail-4
DFHD-68 Horizontal Directional Trenchless Earth Drilling Machine thumbnail-5
DFHD-68 Horizontal Directional Trenchless Earth Drilling Machine thumbnail-6
DFHD-68 Horizontal Directional Trenchless Earth Drilling Machine photo-1
DFHD-68 Horizontal Directional Trenchless Earth Drilling Machine photo-2
DFHD-68 Horizontal Directional Trenchless Earth Drilling Machine photo-3
DFHD-68 Horizontal Directional Trenchless Earth Drilling Machine photo-4
DFHD-68 Horizontal Directional Trenchless Earth Drilling Machine photo-5
DFHD-68 Horizontal Directional Trenchless Earth Drilling Machine photo-6
US$ 180,000 - 220,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, HDD machine
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Zhengzhou Defy Mechanical & Electrical Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, HDD machine
Power Type Diesel
Place of Origin Henan, China
Brand Name DEFY
Model Number DFHD-68
Usage Other, for city pipe laying
Voltage 380V
Power(W) WeiChai243kW / Cummins 239KW
Dimension(L*W*H) 9000*2750*2800mm
Weight 22000kg
Certification ISO, BV, SGS
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description

DFHD-68 Horizontal directional trenchless earth drilling machine

DFHD-68 Horizontal directional trenchless earth drilling machine is widely used for not digging the ground surface, the laying of a variety of underground utilities (pipelines, cables, etc.) a construction machine, which is widely used in water supply, electricity, telecommunications, natural gas, gas, oil and other pipeline laying construction, it is suitable for sand, clay, gravel, etc. conditions.

Technical Parameter
DFHD-68 Horizontal directional trenchless earth drilling machine
1
Main Machine
2
Power
WeiChai243kW / Cummins 239KW
3
Feeding/pulling system
680/680kN
4
Roted rotary torque
27000N.m(45r/min)   13500N.m(90r/min)
5
Rotary speed of main shaft
0-45r/min , 0-90r/min
6
Feeding stroke
6m
7
Pilot hole diameter
φ240mm
8
Drilling angle
8-16°
9
Walking speed
1.5-3.0km/h
10
Structure type
Steel crawler, Motor rack and pinion feeding, cab, crane, mud pump are integrated on one.
11
Crane
2 tons direct-arm Crane
12
Dimension
9000×2750×2800mm
13
Weight
22000kg
14
Mud pump
15
Model
BWF-600
16
Max. Water flow
600L/min
17
Max. Pressure
8Mpa
18
Weight
650kg
19
Pulping system
Optional
20
Auxiliary System
21
Drill rod
φ102×5000mm
22
Pilot drill bit
φ170(φ230)mm
23
Reaming bit
φ425φ500φ680φ760φ820φ920φ1000
24
Transfer case
80T
Drill Tools

Drill Rods                                                                                              Reamer Bits

Guide Bits                                                                                             Detecting Instrument

Packing & Delivery
Working Site

DFHD-68 Horizontal directional trenchless earth drilling machine working in Cambodia

Our Company

ZhengZhou Defy 12 years professional exporting experience, realiable drilling machine manufacturer since 1970S.

Defy offer water well drilling machines drilling depth from 100m, 200m, 400m, 600m, 800m and 1500m. with 75-1500mm diameter. geotechnical core drilling machine from 0-3000m depth.


HDD drilling machine,15ton, 32ton, 68ton, 130ton pulling force for your choices.

Spindle rotary type drilling machine,Horizontal directional trenchless earth drilling machine, pneumatic air operated drilling machine, trailer, crawler, truck mounted drilling machine for your choices.

Please don`t hesitate to contact us if Horizontal directional trenchless earth drilling machine fit for your business. And you are highly appreciated that if you could tell us more details of your business, then we can recommend most suitable model of drilling rig to you.
