UL1569 14AWG 41/0.254mm stranded hook-up wire
- Rated temperature: 105°C
- Rated voltage: 300V
- Reference Standard: UL758, UL1581,CSAC22.2NO.210.2
- Conductor: stranded bare copper conductor 30~10AWG
- Insulation: PVC insulation, comply with ROHS environmental standard
- Flame Retardant Test: UL VW-1, CSA FT1 flame Test
- Uniform thickness to ensure stripping and cutting easily
- For general purpose internal wiring of appliance
MARKING:
E330446 AWM STYLE 1569 AWG NO. 105°C 300V VW-1 --- AWM I A 105°C 300V FT1 RoHS COMPLIANT DANYANG WINPOWER
CONDUCTOR |
INSULATION |
MAX.COND. RESISTANCE (Ω/km,20°C,DC) |
DIELECTRIC STRENGTH (VAC,1min) |
|||
AWG |
CONSTRUCTION (No./mm) |
DIA.(mm) |
THICKNESS (mm) |
O.D. (mm) |
||
20 |
1/0.813 |
0.81 |
1.53 |
4.00 |
35.2 |
2,000 |
26/0.16 |
0.94 |
1.53 |
4.10 |
36.7 |
2,000 |
|
18 |
1/1.024 |
1.02 |
1.53 |
4.20 |
22.2 |
2,000 |
16/0.254 |
1.17 |
1.53 |
4.30 |
23.2 |
2,000 |
|
16 |
1/1.29 |
1.29 |
1.53 |
4.45 |
14 |
2,000 |
26/0.254 |
1.49 |
1.53 |
4.65 |
14.6 |
2,000 |
|
14 |
1/1.63 |
1.63 |
1.53 |
4.80 |
8.78 |
2,000 |
41/0.254 |
1.88 |
1.53 |
5.05 |
8.96 |
2,000 |
|
12 |
65/0.254 |
2.36 |
1.53 |
5.70 |
5.64 |
2,000 |
10 |
105/0.254 |
3.10 |
1.53 |
6.30 |
3.546 |
2,000 |
Packing: 1000ft per roll, to be packed in PE film and carton
Delivery: 3-15days after receiving the down payment
Terms of payment:T/T (30% down payment and pay off after received the duplicate of B/L )
L/C at sight
1. Sample Available
2. OEM are offered
3. Customer wire can be manufactured
4. Convenient transportation
1) Take flight to Shanghai ,and aboard 1 hour train from Shanghai to Danyang.
2) Take flight to Changzhou and aboard 20 minute train from Changzhou to Danyang .
