Specifications
Sand maker:Simple structre,low cost
safe operate,easy maintenance
ISO/SGS Certificate
Widely usage,cubie final product
Sand maker: Sand maker is applied widely for the powder process of mineral product including metal and nonmetalore, fireproof material, bauxite, diamond dust, glass raw materials, architectural
materials, artificial sand and all kinds of metal ore materials, especially which has more advantages
than any other machines in processing the more and most hard materials.
Features:
1.simple structure ,low consumption
2.high efficiency
3.Slightly influenced by moisture content of the raw material
4.Cubic final product
5.Low working noise,light dust pollution
Working principle:the material falls into the high-speed turning impellers from the top of machine and crushes with the materail distributed around the impeller under the effect of high speed centrifugal force.After the impact with each other ,the material is crushed between impeller and cavity and is discharged from the bottom.The material can be milled twice or more times in the whirlpool cavity ,the crushed materials will be excluded through the tottom airflow self-circulation in the whirpool cavity can eliminate the dust pollution well
Technical data
| Technical parameters | ||||||
| type | impeller speed (r/min) | max feed size(mm) | diposal capacity (t/h) capacity (t/h) | power (kw) | weight (t) | overall dimension (mm) |
| PCL-600 | 2000-2470 | 30 | 20-35 | 60-90 | 7.5 | 2800×1500×2030 |
| PCL-750 | 1500-2045 | 35 | 35-55 | 90-150 | 9.3 | 3300×1800×2440 |
| PCL-900(A) | 1200-1685 | 40 | 55-100 | 110-180 | 12.6 | 3750×2120×2660 |
| PCL-603(B) | 1100-1580 | 40 | 65-130 | 150-180 | 14.5 | 3750×2300×2090 |
| PCL-1050 | 1000-1430 | 45 | 90-160 | 180-264 | 17 | 4480×2450×2906 |
| PCL-1250 | 850-1300 | 45 | 160-230 | 364-370 | 22.5 | 4563×2650×3716 |
| PCL-1350 | 800-1185 | 50 | 200-360 | 320-440 | 26.3 | 5340×2940×3650 |
