Specifications
The new cement crusher's jaw head adopts natural water circulation cooling system,to prolong the operating life.The new cement crusher's principle of operation
This machine's eccentric axle is divided into two parts,their eccentric distance is the same, the eccentric direction is opppsite, in each part hanging a dynamic jaw head, the motor propels the eccentric axle through triangle belt by groove wheel, when the eccentric axle rotates, it makes the dynamic jaw do circle drip movement constantly according to the eccentric trail, on oneside the dynamic jaw move to the fixed board to break the materials while the dynamic jaw departing from the fixed jaw board to discharge materials on the other side, alternative operation completes the whole process.
The new cement crusher's performance features
1. The structure is simple and compact, the operation is stable and reliable.
2. Power of the matching parts is small, high-efficiency and save energy.
3. The lengthened jaw board, prevent the materials striking the jaw head.
4. The jaw head adopts natural water circulation cooling system, to prolong the operating life of the bearing part.5. The driving parts adopt advanced multilayer labyrinth craft, to prevent the dust entering the bearing parts.
The new cement crusher's applicability
1. Widely applied to all sorts of materials' break whose compressive strength below 250Mpa.
2. Especially applied to the finement of clinker and high-temperature materials.
| Model | Size(mm) | Feed Size(mm) | Discharge Size(mm) | Productivity(t/h) | Power of Motor（Kw） |
| PEX-250×1000 | 1340*1925*1400 | ≤210 | 25-60 | 10-40 | 30 |
| PEX-250×1200 | 1495*2125*1400 | ≤210 | 25-60 | 15-50 | 37 |
| PEX-300×1300 | 1670*2156*1550 | ≤250 | 25-90 | 20-70 | 75 |
| P2EX-250*1000 | 1225*1820*1205 | <=210 | 15-50 | 10-37 | 11 |
| P2EX-250*1200 | 1238*2000*1390 | <=210 | 15-60 | 15-46 | 15 |
