Specifications
sieve machineThis steel wire screen is widely applied to the sizing of building materials, metallurgy, chemical industry, road
Sieve machine
YK sieve machine is steel wire screen which has 4 blankets of combination, the longitudinal cardan-shaft machine make it simulteneous operation reach the best vibrating result. the type jointing axle machine pass the motor's rotation to the axion's axle, under the function of the eccentric bulk, the roller axle do unequal centrifugal force rotation, the major machine realizes the full vibration under the support of spring to size the material.
Performance features of sieve machine
1. The mortor adopts type coupled axle machine, prevent the motor being wore for twisting when it is starting.
2. Adopt rubber spring, the whole machine's operation is stable and reliable, the operating life is long.
3. Adopt combined exciter and cardon movement, to assure the operation simultaneous, exclude the phenominon of bearing effecting the operating life as its coaxial degree is not very good.
4. Adopt aircooling craft,reducing the bearing temperature, prolonging the bearing temperature, prolonging the bearing's operating life.
5. Adopt high-strength bolted combinate craft, make the sieve body's operating life more durable under the full vibration.
| Model | Screen Deck | Dip of Groove Surface (degree) | Capacity (t/h) | Motor power (KW) |
| YK-1548 | 1 | 20 | 50-200 | 11 |
| 2YK-1548 | 2 | 20 | 50-200 | 11 |
| 3YK-1548 | 3 | 20 | 50-200 | 15 |
| 4YK-1548 | 4 | 20 | 50-200 | 18.5 |
| YK-1860 | 1 | 20 | 80-280 | 18.5 |
| 2YK-1860 | 2 | 20 | 80-280 | 18.5 |
| 3YK-1860 | 3 | 20 | 80-280 | 22 |
| 4YK-1860 | 4 | 20 | 80-280 | 22 |
| 2YK-2160 | 2 | 20 | 100-450 | 22 |
| 3YK-2160 | 3 | 20 | 100-450 | 30 |
| 4YK-2160 | 4 | 20 | 100-450 | 30 |
