Managed Gigabit 8 Port SFP Fiber Optical Ethernet Switch 12V
Overview
HiOSO FOWAY1509FC is a nine ports Gigabit fiber switch, with 8 1000M SFP fiber ports and 1 1000M Combo port (100M / 1000M SFP port or 10/100/1000M RJ45 port optional) uplink.
FOWAY1509FC supports SFP modules hot plug, and supports to work with fiber switches, fiber converters and other devices witch fiber ports. It supports WEB management; applies to security system, electric system, traffic system requirements.
Character
l Support 8 Gigabit SFP access and 1 Gigabit Combo port (100M or 1000M SFP optional, or 10/100/1000M RJ45 port)
l Support SFP hot plug
l Support full rate, full-duplex non-blocking forwarding at each port
l Support 8K MAC learning, 1Mbit storage and forward cache space, 18G back plane bandwidth
l Supports to substitute central fiber converter, simplify network structure, lower network establishing cost, reduce device fault
l All optic ports, strengthen the an-interference ability
l Metal casing design, better for heat dissipation
Technical Specification
Parameter |
Specification |
Standard |
IEEE802.3 10Base-T Ethernet,IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX Gigabit Ethernet, IEEE802.1d Spanning Tree |
Wavelength |
SFP:850nm/1310nm/1490nm/1550nm |
Distance |
100M SFP Multi-mode: 2km (fiber size 62.5/125μm or 50/125μm) Single-mode: 20/40/60/80/100/120Km Single-fiber single-mode: 25/40/60/80/100/120Km 1000M SFP Multi-mode: 220m (fiber size 62.5/125μm) / 550m(fiber size 50/125μm) Single-mode: 10/20/40/60/80/100/120Km Single-fiber single-mode:10/20/40/60/80/100/120Km |
Port |
8 Gigabit SFP fiber ports: 1000Mbps 1 Gigabit Combo port:: 1 Gbps, 100M/1000M SFP&10/100/1000M RJ45 |
MAC |
8K |
Buffer memory space |
1Mbit |
Bit error rate |
<1/1000000000 |
MTBF |
100000 hours |
Power |
DC12V/2A |
Power consumption |
10W |
|
Working temperature |
-10~60℃ |
Storage temperature |
-40~80℃ |
Humidity |
5%~90% non-condensing |
Dimension |
28mm (H)×193mm(W)×119mm (D) |
Order information
No |
Type |
Managed |
Ports |
1 |
FOWAY1509FC |
Not |
8 1000Base-FX SFP ports + 1 Gigabit Combo uplink (SFP fiber port /RF45 Ethernet port optional) |
2 |
FOWAY1509FCM |
Support |
8 1000Base-FX SFP ports + 1Gigabit Combo uplink ((SFP fiber port /RF45 Ethernet port optional) |
