100/1000M Optical Switch 24 Port Managed Switch
Overview
HiOSO FOWAY3000-26FSC is a 26 ports 100M and1000M hybrid all optic fiber switch. It offers 24 100M SFP fiber ports access and 2 Gigabit Combo port (100/1000M SFP port or 10/100/1000M adaptive RJ45 Ethernet optional) uplink.
FOWAY3000-26FSC supports SFP modules hot plug, and supports to work with fiber switches, fiber converters and other devices witch fiber ports. It supports WEB management; applies to security system, electric system, traffic system requirements. It supports dual power hot backup and DC12V/5A power supply.
Character
l Support maximum 24 SFP fiber ports and 2 GE Combo port (SFP fiber port/RJ45 port interchange)
l Support SFP hot plug
l Support each port full rate, full-duplex non-blocking forwarding
l Support 8K MAC learning, 3Mbit storage and forward cache space, 8.8G back plane bandwidth
l Supports to substitute central fiber converter, simplify network structure, lower network establishing cost, reduce device fault
l Replace Media Converter in machine room side, simple network structure, reduce network system total cost and reduce device faults
l All optic ports, strengthen the an-interference ability
l 1U rack type, supports max 3 pieces power supply hot backup ( 2 piece inside power supply AC100V~240V input access and 1 piece DC12V output access)
l DC12V/5V input port supports car battery access to ensure network working when the public power supply system is black out
Technical Specification
Parameter |
Specification |
Standard |
IEEE802.3 10Base-T Ethernet,IEEE802.3u 100Base-TX/FX Fast Ethernet, , IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX Gigabit Ethernet, , IEEE802.1d Spanning Tree, IEEE802.1w Rapid Spanning Tree, IEEE802.1s Multiple Spanning Tree, IEEE802.1q VLAN, IEEE802.1p QoS |
Wavelength |
SFP module: 850nm/1310nm/1550nm |
Distance |
100M SFP multi-mode: 2Km Single-mode: 20/40/60/80/100/120Km Single-fiber single-mode: 25/40/60/80/100/120Km 1000M SFP multi-mode:220mfiber 62.5/125μm)/ 550m(fiber 50/125μm) Single-mode:10/20/40/60/80/100/120Km Single-fiber single-mode: 10/20/40/60/80/100/120Km |
Port |
24 100M SFP fiber ports: 100Mbps 2 Gigabit Combo ports:1 Gbps, 100/1000M SFP&10/100/1000M RJ45 |
MAC |
8K |
Buffer memory space |
3Mbit |
Bit error rate |
<1/1000000000 |
MTBF |
100000 hours |
Power |
AC100~240V 50/60HZ, DC12V/5A |
Power consumption |
50W |
|
Working temperature |
-10~60℃ |
Storage temperature |
-40~80℃ |
Humidity |
5%~90% non-condensing |
Dimension |
44mm (H)×440mm(W)×210mm (D) |
Ordering information
NO |
Type |
Management |
Ports |
Power Supply |
1 |
FOWAY3000-26FSC |
NO |
24 100M SFP ports +2 Gigabit Combo uplink ports |
Inside single power supply |
2 |
FOWAY3000-26FSC-BP |
NO |
24 100M SFP ports + 2 Gigabit Combo uplink ports |
Inside dual power supply |
3 |
FOWAY3000-26FSCM |
YES |
24 100M SFP ports + 2 Gigabit Combo uplink ports |
Inside single power supply |
4 |
FOWAY3000-26FSCM-BP |
YES |
24 100M SFP ports + 2 Gigabit Combo uplink ports |
Inside dual power supply |
Certificates
