100/1000M 16SFP ports +2 Combo ports(TP or SFP) Ethernet Fiber Switch
Overview
HiOSO FOWAY3000-18FSC is a 18 ports 100M and1000M hybrid all optic fiber switch. It offers 16 100M SFP fiber ports access and 2 Gigabit Combo port (100/1000M SFP port or 10/100/1000M adaptive RJ45 Ethernet optional) uplink.
FOWAY3000-18FSC supports SFP modules hot plug, and supports to work with fiber switches, fiber converters and other devices witch fiber ports. It supports WEB management and SNMP management; applies to security system, electric system, traffic system requirements.
Character
l Support maximum 16 SFP fiber ports and 2 GE Combo port (SFP fiber port/RJ45 port interchange)
l Support SFP hot plug
l Support each port full rate, full-duplex non-blocking forwarding
l Support 8K MAC learning, 2Mbit storage and forward cache space, 7.2G back plane bandwidth
l Supports to substitute central fiber converter, simplify network structure, lower network establishing cost, reduce device fault
l All optic ports, strengthen the an-interference ability
l Metal casing design, better for heat dissipation, supports 1U rack installation
Technical Specification
Parameter |
Specification |
Standard |
IEEE802.3 10Base-T Ethernet,IEEE802.3u 100Base-TX/FX Fast Ethernet, , IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX Gigabit Ethernet, , IEEE802.1d Spanning Tree, IEEE802.1w Rapid Spanning Tree, IEEE802.1s Multiple Spanning Tree, IEEE802.1q VLAN, IEEE802.1p QoS |
Wavelength |
SFP module: 850nm/1310nm/1550nm |
Distance |
100M SFP multi-mode: 2Km Single-mode: 20/40/60/80/100/120Km Single-fiber single-mode: 25/40/60/80/100/120Km 1000M SFP multi-mode:220mfiber 62.5/125μm)/ 550m(fiber 50/125μm) Single-mode:10/20/40/60/80/100/120Km Single-fiber single-mode: 10/20/40/60/80/100/120Km |
Port |
16 100M SFP fiber ports: 100Mbps 2 Gigabit Combo ports:1 Gbps, 100/1000M SFP&10/100/1000M RJ45 |
MAC |
8K |
Buffer memory space |
2Mbit |
Bit error rate |
<1/1000000000 |
MTBF |
100000 hours |
Power |
AC100~240V 50/60HZ |
Power consumption |
20W |
|
Working temperature |
-10~60℃ |
Storage temperature |
-40~80℃ |
Humidity |
5%~90% non-condensing |
Dimension |
44mm (H)×277mm(W)×190mm (D) |
Solutions
