Foam Concrete Pump
- Qingdao
- T/T
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | SYM | |
| Model Number | SYT-30 | Theory | Reciprocating Pump | |
| Structure | Piston Pump | Usage | Other, Cellular lightweight concrete | |
| Power | Hydraulic | Standard or Nonstandard | Standard | |
| Fuel | Other, electric | Pressure | High Pressure | |
| Application | Other, conveying cement grout |
Product Description
Specifications
1- Adopting wear resistant metal, sturdy and durable.2- Full automatic control system, to adjust the foam concrete density
SYT-30 Hydraulic Concrete pump
A. Features:
1- Adopting wear resistant metal, sturdy and durable.
2- Full automatic control system, to adjust the foam concrete density easily.
3- Adopting the famous brand good quality components, reliable quality.
4- Adopting hydraulic two cylinders single conveying way to send the foam concrete to the construction plant on-site, stable flow, small fluctuation.
5- Equipped with travelling wheel, easy moving and position.
6- Equip the remote control handle with the electric cabinet, convenient operation.
B. Technical Data:
Max. theoretical grouting flow: 30m3/h
Max. theoretical conveying pressure: 8Mpa
Max. theoretical horizontal transporting range: 600m
Max. theoretical vertical transporting height: 200m
Max. particle aggregate size: 8mm
Max. pressure of hydraulic system: 24Mpa
Oil pressure box volume: 200L
Motor: 30kw
Dimension: 3100*920*1300 mm
Weight: 1900kg
