Home > Products > Foam Concrete Pump > Concrete Pump for Foam Concrete Slurry
Concrete Pump for Foam Concrete Slurry
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Other, Lightweight Foam Concrete Block Making Machine | |
| Brick Raw Material | Other, Flyash, Fine sand, Stone Powder, Cinder etc. | Processing | Brick Production Line | |
| Method | Hydraulic Pressure | Automatic | Yes | |
| Capacity | 20-30m3/hour | Place of Origin | Henan, China | |
| Brand Name | SYM | Model Number | SYT-30 | |
| Voltage | 380V | Power | 30kw | |
| Dimension(L*W*H) | 3100*920*1300 mm | Warranty | 12months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Foam concrete pump speically used for pumping cement mortar, sand pulp etc. Hydraulic pressure could be adjusted.SYT-30 Hydraulic Foam Concrete Pump
Features:
1. Adopting wear resistant metal, sturdy and durable.
2. Full automatic control system, to adjust the foam concrete density easily.
3. Adopting the famous brand good quality components, reliable quality.
4. Adopting hydraulic two cylinders single conveying way to send the foam concrete to the construction plant on-site, stable flow, small fluctuation.
5. Equipped with travelling wheel, easy moving and position.
6. Equip the remote control handle with the electric cabinet, convenient operation.
Technical Data:
ITEM | DATA |
Max. theoretical grouting flow | 30 m³/h |
Max. theoretical conveying pressure | 8 Mpa |
Max. theoretical horizontal transporting range | 600 m |
Max. theoretical vertical transporting height | 200 m |
Max. particle size of aggregates | 8 mm |
Pump head quantity | 2 Pcs |
Oil cylinder (material cylinder) quantity | 2 Pcs |
Oil cylinder inside diameter*stroke | Φ80*1000 mm |
Material cylinder inside diameter*stroke | Φ140*1000 mm |
Max. pressure of hydraulic system | 24 Mpa |
Oil pressure box volume | 200L |
Motor power | 30 KW |
Dimension (L*W*H) | 3100*920*1300 mm |
Weight (whole machine) | 1900 kg |
