China New Product Automatic Machine Continous Ball Mill

Specifications

China New Product Automatic Machine Continous Ball Mill
ISO certificated
Easy structure,convenient maintenance,super quality

China New Product Automatic Machine Continous Ball Mill



Introduction of Continous Ball Mill

Ball mill is key equipment to grind the crushed materials, and the ball mill with medium hard is widely used in powder-making production line including cement, silicate, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and non-ferrous metal, glass ceramics etc. It is manufactured with the highest quality materials and workmanship and it has the advantages of high efficient, trouble free and economical combination of material ranging from (5-30mm) down to varying product sizes. Ball Mill is an efficient tool for grinding many materials into fine powder.

The Ball Mill is used to grind many kinds of mine and other materials, or to select the mine. It is widely used in building material, chemical industry etc. There are two ways of grinding: the dry process and the wet process. It can be divided into tabular type and flowing type according to different forms of discharging materials.



Working Principle of Continous Ball Mill

According to the discharging type, ball mill could be divided into three types, overflow type ball mill, open-type ball mill and peripheral type ball mill. Overflow type ball mill is the most common one. As the first class open grinding equipment, ball mill is widely used for first class grinding equipment of concentrator, artificial sand stone and electricity sector of chemical plants. The ball mill rotation is based on deceleration motor and large gear deceleration rotation or large gear deceleration rotation which is driven by low speed synchronous motor, and then drives ball mill cylinder rotating. Steel bar, the grinding media is installed in cylinder; media is promoted to a certain height because of the joint action of friction and centrifugal force, and is dropping or falling off. The grinding materials are continuously feeding into the cylinder through inlet of ball mill, crushed by steel bar and discharge the finished products out of ball mill by overflow and continuous feeding strength then go to the next process.



Features of Continous Ball Mill

1. Wide range of applications, simple structure and convenient maintenance;

2. Large capacity and continuous work ;

3. Barrel lining and grinding media can apply various abrasive materials;

4. Installation and adjustment are very convenient and easy to be operated.



Technical Parameters of Continous Ball Mill

Model	Shell rotation speed(r/min) Shell rotation speed(r/min)	Ball load(t)	Feeding size(mm)	Discharging size(mm)	Capacity	Motor power(kw)	Total weight(t)
900*1800	36 -- 38	1.5	<=20	0.075-0.89	0.65-2	18.5	5.5
900*3000	36	2.7	<= 20	0.075-0.89	1.1-3.5	22	6.7
1200*2400	36	3	<=25	0.075-0.6	1.5-4.8	30	12
1200*3000	36	3.5	<=25	0.074-0.4	1.6-5	37	12.8
1200*4500	32.4	5	<=25	0.074-0.4	1.6-5.8	55	13.8
1500*3000	29.7	7.5	<=25	0.074-0.4	2-5	75	16.8
1500*4500	27	12	<=25	0.074-0.4	3-6	110	21
1500*5700	28	11	<=25	0.074-0.4	3.5-6	130	25.8
1830*3000	25.4	15	<=25	0.074-0.4	4-10	130	29
1830*4500	25.4	21	<=25	0.074-0.4	4.5-12	155	35.5
1830*6400	24.1	23	<=25	0.074-0.4	6.5-15	210	43
1830*7000	24.1	15	<=25	0.074-0.4	7.5-17	245	43.8
2100*3000	23.7	24	<=25	0.074-0.4	6.5-36	155	34.8
2100*4500	23.7	26	<=25	0.074-0.4	8-43	245	38
2100*7000	23.7	27	<=25	0.074-0.4	8-48	280	56.6
2200*4500	21.5	35	<=25	0.074-0.4	9-45	280	51.8
2200*6500	21.7	35	<=25	0.074-0.4	14-26	380	60
2200*7000	21.7	35	<=25	0.074-0.4	15-28	380	62
2200*7500	21.7	23	<=25	0.074-0.4	15-30	380	64.8
2400*3000	21	40	<=25	0.074-0.4	7-50	245	54
2400*4500	21	30	<=25	0.074-0.4	8.5-60	320	65
2700*4000	20.7	40	<=25	0.074-0.4	12-80	380	94
2700*4500	20.7	48	<=25	0.074-0.4	12-90	480	102
3200*4500	18	65	<=25	0.074-0.4	-----	800	137
3600*4500	17	90	<=25	0.074-0.4	-----	850	158
3600*6000	17	110	<=25	0.074-0.4	-----	1250	175
3600*8500	18	131	<=25	0.074-0.4	45.8-256	1800	252
4000*5000	16.9	121	<=25	0.074-0.4	45-208	1500	203
4000*6000	16.9	146	<=25	0.074-0.4	65-248	1600	213
4000*6700	16.9	149	<=25	0.074-0.4	45-252	1800	238
4500*6400	15.6	142	<=25	0.074-0.4	54-306	2000	280
5030*6400	14.4	216	<=25	0.074-0.4	68-386	2500	320
5030*8300	14.4	266	<=25	0.074-0.4	88-500	3300	403
5500*8500	13.8	338	<=25	0.074-0.4	108-615	4500	525
