automatic wire nail machine

Specifications

automatic wire nail machine
1.high speed
2.low noise and friction
3.easy and safe operation
4.wide usage

Automatic wire nail machine

Main feature of automatic wire nail machine:

Z94 Type C New Generation High Speed, Low Noise, Automatic wire nail machine

This new type wire nail  machines adopt plunger structure and oil pipe lubrication so as to ensure the features such as high speed,low noise and less impact. Especially, it can make the high quality of clout nails and other special nails used for high speed coil nail welder and nail gun.



This automatic wire nail machines have the reasonable structure ,excellent performance, advanced craftwork and the quality of products reaches the international advanced level.



This automatic wire nail machine can make all kinds of round steel. steel nail. oil rivet nail, corrugated nail, double cap nail. U nail. twist nail. horizontal line nail. pneumatic gun nail(also named code nail, straight nail, line nail or midge nail).

 Specification of automatic wire nail machine:

Technical data	Unit	Z94 -6.5C	Z94 -5.5C	Z94 -4C	Z94 -3C	Z94 -2C	Z94 -1C
Dia of nail max	mm	6.5	5.5	4.5	3.4	2.8	1.6
Dia of nail min	mm	4.5	3.7	2.8	1.8	1.2	0.9
Length of nail max	mm	200	150	100	75	50	25
Length of nail min	mm	100	80	50	30	16	9
Designed capacity	pcs/min	160	200	280	320	350	450
Motor power	kw	11	5.5	4	3	2.2	1.5
Weight(approx)	kg	5000	2500	2000	1600	1400	1200

 Processing flow of automatic wire nail machine:

 steel wire ----wires-drawing ----nail-making ----polishing---- packing

The show of automatic wire nail machine:



 The end products--nails of automatic wire nail machine:
