Home > Electrical & Electronics > Telecommunication & Broadcasting > WiFi Products > 2.4GHz 802.11b/g/n 300Mbps RJ45 Wireless WiFi Wimax Repeaters

2.4GHz 802.11b/g/n 300Mbps RJ45 Wireless WiFi Wimax Repeaters

Name: 2.4GHz 802.11b/g/n 300Mbps RJ45 Wireless WiFi Wimax Repeaters
Brand: topdoss
SKU: 116443519
Availability: InStock

2.4GHz 802.11b/g/n 300Mbps RJ45 Wireless WiFi Wimax Repeaters thumbnail-1

2.4GHz 802.11b/g/n 300Mbps RJ45 Wireless WiFi Wimax Repeaters photo-1

US$ 15 - 21 MOQ: 50 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

topdoss

Model Number:

TD-2R

Contact Supplier Request Quote Chat Now

Shenzhen TopDoss Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name topdoss

Model Number TD-2R

Specifications

1.2.4GHz 802.11b/g/n 300Mbps RJ45 Wireless WiFi wimax Repeaters
2.Repeaters
3.Fast delivery
4.Fast delivery

2.4GHz 802.11b/g/n 300Mbps RJ45 Wireless WiFi wimax Repeaters

Improve wireless coverage in all WLAN networks.
Support Wireless Repeater Mode and Standard AP Mode.
WLAN 802.11n for wireless high-speed access, downwards compatible with 802.11g(54Mbit/s) and 802.11b(11Mbit/s) standard.
Provides up to 300Mbps transmission rates.
Support 2.4GHz WLAN networks.
Maximum WLAN security with WPA2, WPA and WEP(128/64).
Software wizard for simple setup.
Antennas integrated.
WLAN access point/client according to IEEE 802.11n/g/b.
110 ~ 230-volt socket.
The WLAN client must support at least the WPA encryption standard.
WLAN access point and the WLAN client with automatic IP address assignment(DHCP).
Forwarding of IPv4-based protocols/Address Resolution Protocol.
The network name (SSID) of the WLAN access point must be set to "visible".

Wireless
Standard	IEEE802.11b, IEEE 802.11g, IEEE 802.11n
Modulation	802.11b: DSSS / BPSK / QPSK / CCK
	802.11g: OFDM / DSSS / BPSK / QPSK / CCK
	802.11n: OFDM / DSSS / BPSK / QPSK / CCK
Speed	802.11b: 11Mbps 802.11g: 54Mbps 802.11n: 300Mbps
Channel	11: (Ch.1-11) - USA 13: (Ch.1-13) – Europe 14: (Ch.1-14) – Japan
Frequency band	2.412~2.462GHz –USA 2.412~2.472GHz –Europe ETSI 2.412~2.484GHz –Japan
Power	802.11b: 17dBm ± 1.5 dBm 802.11g: 14dBm ± 1.5 dBm 802.11n: 14dBm ± 1.5 dBm
Sensitivity	802.11b: -83dBm /802.11g: -70dBm / 802.11n: -68dBm
Antenna	2 x 3dBi Integrated Antennas
Distance	Outdoors 300m, Indoor 100m (According to the actual environment change)
Security	64/128-bit WEP, AES, TKIP, WPA, WPA2, 802.1x, WPA-PSK, WPA2-PSK, MAC, WDS
Software
Standard Version	RFC768 User Datagram Protocol(UDP) RFC791 Internet Protocol(IP) RFC792 Internet Control Message Protocol RFC793 Transmission Control Protocol(TCP) bandwidth: 20MHz, 40MHz, Automatic(option) Wireless Mode: 11n only, 11 b/g/n mixed, 11 b/g mixed, 11g only, 11b only(option)
Mode	AP Mode / Repeater Mode
Wireless Security	Wireless MAC address Screening Wireless security function switch 64/128/152-bit WEP WPA-PSK/WPA2-PSK, WPA/WPA2
Function	IP bandwidth control (Router mode support) DNS Relay (Router mode support) VPN Pass-through (Router mode support) Static Router (Router mode support) DHCP Server (Router mode support)
DHCP settings	Server list (Router mode support) Static IP address allocation (Router mode support)
Security Settings	IP and MAC address binding against ARP attacks (Router mode support) IP address Screening (Router mode support) Name Screening (Router mode support) MAC address Screening (Router mode support)
System Tools	Traffic statistics System Journal
Hardware
Ports	1 x RJ45 Jack
Button	Reset WPS
LED	1 * LAN, 1 * WLAN, 1 * Power, 1 * WPS
Chipset	RTL8196E
Flash	16Mbps
SDRAM	128Mbps
Power supply	Internal DC5V / 1A
Power plug	EU plug
Power consumption	2.3W
Rated voltage/ frequency /current	100-240 VAC 50/60Hz, 0.1A Max.,
Environmental
Operating temperature	0 ~ 40 Celsius degree
Storage temperature	-10 ~ 70 Celsius degree
Relative humidity	10% ~ 90% (Non Condensation)
Product information:
Color	White + Black
Product size	Approx. 9.5 * 8cm / 3.74 * 3.15in
Product weight	Approx. 108g / 3.8oz
Package size	Approx. 18 * 11.8 * 6.6cm / 7.09 * 4.65 * 2.6in
Package weight	Approx. 218g / 7.68oz
