Home > Electrical & Electronics > Telecommunication & Broadcasting > WiFi Products > PIM3-150dBC IP65 800-2700MHZ Directional Coupler
PIM3-150dBC IP65 800-2700MHZ Directional Coupler
Negotiable
MOQ: 500 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
tianxing
Model Number:
800-2700NHZ
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
5dB/6dB/7dB/10dB/15dB/20dB/25dB/30dB/ 800-2500MHZ RF Directional CouplerNegotiableMOQ: 500 Pieces -
PIM3-150dBC IP65 800-2500MHZ Directional CouplerNegotiableMOQ: 500 Pieces
-
800-2500MHZ Indoor RF Directional Coupler With N-F ConnectorNegotiableMOQ: 500 Pieces
-
5dB/6dB/7dB/10dB/15dB/20dB/25dB/30dB/ 800-2700MHZ RF Directional CouplerNegotiableMOQ: 5000 Pieces
-
Hot Sale RF Directional CouplerNegotiableMOQ: 500 Pieces
Place of Origin
Jiangsu, China
Brand Name
tianxing
Model Number
800-2700NHZ
PIM3-150dBC IP65 800-2700MHZ directional coupler
1. technical specification
| 800 - 2700MHz N-Female Cavity Directional Coupler | |||||||||
| Coupling(dB) | 5 | 6 | 7 | 8 | 10 | 15 | 20 | 25 | 30 |
| In-band Ripple(dB) | ±0.8 | ±0.8 | ±0.8 | ±0.8 | ±1.0 | ±1.0 | ±1.0 | ±1.0 | ±1.0 |
| VSWR | ≤1.25 | ||||||||
| Insertion Loss(dB) | ≤2.0 | ≤1.6 | ≤1.35 | ≤1.1 | ≤0.7 | ≤0.4 | ≤0.3 | ≤0.2 | ≤0.2 |
| Isolation(dB) | ≥25 | ≥26 | ≥27 | ≥28 | ≥30 | ≥35 | ≥40 | ≥45 | ≥50 |
| PIM3(dBc) | ≤-150@ + 43dBmx2 | ||||||||
| Impedance(Ω) | 50 | ||||||||
| Power Rating(W) | 300 | ||||||||
| Connector | N-F | ||||||||
| Application | Outdoor, IP65 | ||||||||
| Temperature Range(°C) | -30~+70 | ||||||||
2. Product show
3. Factory bulding
Company Information
4. shipment
Packaging & Shipping
1. packing: the packing are according to your instruction.
2. shipping: the sample will be arranged within 7 days, and the order shippment will be arranged according to the quatity.
5. Contact us
Sales: Eve Yao
Skype: trade. eve
web:
Tel: 86 511 83565358
Fax: 86 511 83565357
We sincerely welcome all interested buyers to visit our factory and contact us directly for further information, we will reply you as soon as possible!
