38mm IP65 Stainless Steel Optical Trackball Module
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Key-Tek
Model Number:
K-TEK-38-OTB
Payment & Shipping
Payment Methods:
Port of Shipment:
Shen Zhen and HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
IP68 Rated Washable 16mm Stainless Steel Optical Trackball MouseNegotiableMOQ: 1 Set -
50mm Resin Mechnical Trackball With IP65 RatedNegotiableMOQ: 1 Set
-
2016 New Rear Panel Mounting IP65 Industrial Metal Ruggedized TouchpadUS$ 89 - 199MOQ: 1 Piece
-
38mm Waterproof Vandal Proof Stainless Steel Trackball Pointing MouseNegotiableMOQ: 1 Set
-
IP68 Washable Optical Metal TrackballNegotiableMOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
Key-Tek
Model Number
K-TEK-38-OTB
38mm IP65 stainless steel Optical trackball module
Model NO:K-TEK-38-OTB
Dimension: 54.0mm x 74.0mm (front panel)
Description:IP68 dynamic rated washable 38mm Optical trackball module with 800 DPI resolutions for fast and accurate cursor position with extremely smooth operation without any noise.
TECHNICAL SPECIFICATION
| ITEM | SPECIFICATION | |
| Mechanical Data | Ball diameter | 38mm/1.50' (19mm, 25mm, 36mm 40mm also available) |
| Track ball lifespan | > 5 Mio revolutions | |
| Actuation Force | 1.0N to 3.0N | |
| Dimension | 38 .1 mm diameter for ball, 57.0mm x 74.0mm (front panel) | |
| Interface | PS2, USB are available, Y type cable with ports of PS2 and USB | |
| Electrical | Power supply | 5V DC+ 10%, keyboard interface |
| Protection level | IP65 dynamic, NEMA3 | |
| EMC Standard | EN55022(B) | |
| Power consuming | ≤1.00W(dynamic) | |
| ≤0.2W(static) | ||
| Environmental | Operating temperature | -20ºC~+ 60º C |
| Storage temperature | - 30ºC~+ 70ºC | |
| Operating RH | 30~90% | |
| Atmospheric pressure | 60106Kpa. | |
| Reliable | Certificates | RoHS compliant, CE and FCC certified. |
| MTBF | >20000h | |
| MTTR | < 30min | |
| OS | DOS/Windows95/98/NT/ME/2000/2003/XP/Vista,WIN7, Linux, Unix, Mac OSX | |
| Packing Details | Each unit to a suitable brown inner box, suitable brown inner boxes to a standard export carton. | |
