IP65 Ruggedized Touchpad With Integrated Water Proof Keypad
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Key-Tek
Model Number:
K-TEK-B160TP-KP
Payment & Shipping
Payment Methods:
Port of Shipment:
Shen Zhen and HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
38mm IP65 Mechanical Trackball ModuleNegotiableMOQ: 1 Set -
38mm IP65 Laser Trackball ModuleNegotiableMOQ: 1 Set
-
50mm Desk Top Stainless Steel TrackballNegotiableMOQ: 1 Set
-
Movable Desktop Metal TouchpadNegotiableMOQ: 1 Set
-
Stand Alone Metal Industrial Touchpad Pointing Device With Numeric KeypadNegotiableMOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
Key-Tek
Model Number
K-TEK-B160TP-KP
Model NO:K-TEK-B160TP-KP
Dimension:160.0mm x 125.0mm (top panel)
Description:IP65 dynamic sealed and ruggedized tough touchpad with scroll function (optional) for fast and accurate cursor position, industrial metal dome PCB with gold-on-gold key switch technology with short stroke 0.45mm with excellent tactile feeling for stable and accurate data input, with numeric keypad integrated, stainless steel top plate with threaded bolts for top panel mounting solution.
TECHNICAL SPECIFICATION
| ITEM | SPECIFICATION | ||
| Mechanical | Front Plate | Quality brushed stainless steel | |
| Touchpad thickness | 1.3 mm PCB thickness inclusive of mylar layer | ||
| Validated touch width | 46.50mm (max) | ||
| Validated touch length | 62.50mm (max) | ||
| Mounting Rack | Aluminum alloy | ||
| Back Metal Cover | Rear side integrated electronics protected by a metal cover | ||
| Touchpad lifespan | > 10 Mio times | ||
| Dimensions | Touchpad: 65.0mm x 49.0mm; Front Mounting Panel: 160.0mm x 125.0mm (front panel), | ||
| Interface | PS2 and USB both available | ||
| Electrical | Power supply | 5V DC+ 10%, | |
| Work current | 4.0 mA (normal) | ||
| X/Y position sensing resolution: | 1000 points/inch (40 points/mm) | ||
| X/Y position reporting: | Relative | ||
| Tracking speed: | Maximum 1,016 m/sec | ||
| Protection level: | IP65 (front panel) | ||
| Static Release: | 15 KV (front panel) | ||
| EMC Standard: | EN55022(B) | ||
| Environmental | Operating temperature: | -20°C to +60°C | |
| Storage temperature: | - 40°C to + 70°C | ||
| Operating RH: | 10%-95% | ||
| Atmospheric pressure: | 60-106Kpa | ||
| Reliability | MTBF | >20000h | |
| MTTR | < 30min | ||
| Touchpad Lifespan | >10 million actuations | ||
| OS | OS is under DOS/Windows95/98/NT/ME/2000/XP/2003/Vista,WIN7, Linux, Unix, Mac OS9 / OSX | ||
| Packing Details | Each unit to a suitable brown inner box, suitable brown inner boxes to a standard export carton. | ||
