Stand Alone Metal Industrial Touchpad Pointing Device With Numeric Keypad
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Key-Tek
Model Number:
K-TEK-A160TP-KP-DT
Payment & Shipping
Payment Methods:
Port of Shipment:
SHEN ZHEN AND HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
IP68 Washable Industrial Laser Trackball Pointing DeviceNegotiableMOQ: 1 Set -
IP68 Dynamic Washable Sealed Metal Laser TrackballNegotiableMOQ: 1 Set
-
Functional Sealed-and-ruggedized Touchpad Module With All Black DesignNegotiableMOQ: 1 Piece
-
All Black Titanium Pointing Device With Tracking MouseNegotiableMOQ: 1 Piece
-
Vandal Proof Mouse Trackball in Factory PriceNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Key-Tek
Model Number
K-TEK-A160TP-KP-DT
Application
Computer Keyboard
Keypad Button Material
Metal
IP65 desk top ruggedized touchpad with integrated keypad,with carbon-on-gold key switch technology.
TECHNICAL SPECIFICATION
| ITEM | SPECIFICATION | ||
| Mechanical | Front Plate | Quality brushed stainless steel | |
| Touchpad thickness | 1.3 mm PCB thickness inclusive of mylar layer | ||
| Validated touch width | 46.50mm (max) | ||
| Validated touch length | 62.50mm (max) | ||
| Mounting Rack | Aluminum alloy | ||
| Back Metal Cover | Rear side integrated electronics protected by a metal cover | ||
| Touchpad lifespan | > 10 Mio times | ||
| Dimensions | Touchpad: 65.0mm x 49.0mm; 160.0mm x 125.0mm x 20.0mm (L x W x H) |
||
| Interface | PS2 and USB both available | ||
| Electrical | Power supply | 5V DC+ 10%, | |
| Work current | 4.0 mA (normal) | ||
| X/Y position sensing resolution: | 1000 points/inch (40 points/mm) | ||
| X/Y position reporting: | Relative | ||
| Tracking speed: | Maximum 1,016 m/sec | ||
| Protection level: | IP65 (front panel) | ||
| Static Release: | 15 KV (front panel) | ||
| EMC Standard: | EN55022(B) | ||
| Environmental | Operating temperature: | -20°C to +60°C | |
| Storage temperature: | - 40°C to + 70°C | ||
| Operating RH: | 10%-95% | ||
| Atmospheric pressure: | 60-106Kpa | ||
| Reliability | MTBF | >20000h | |
| MTTR | < 30min | ||
| Touchpad Lifespan | >10 million actuations | ||
| OS | OS is under DOS/Windows95/98/NT/ME/2000/XP/2003/Vista, Linux, Unix, Mac OS9 / OSX | ||
| Packing Details | Each unit to a suitable brown inner box, suitable brown inner boxes to a standard export carton. | ||
