Low Cost and High Performance New LB series asphalt batch mix plant
LB series batch forced asphalt mixing plant is a new product based on advanced technology of German. Adopt container design which enhance the stability and compactness of equipment, save space.Tower typed finished products storage silo with gravity filler connection, Reliable Performance.environmental and energy-saving, convenient transportation and transfer.widely used in the construction of road, airport, port, water conservancy, and city concrete products, etc
Features of the LB Series asphalt batch mixing plant
The modular design makes the transportation and installation convenient and fast.
• Fuel types: diesel, heavy oil and natural gas are available for lower operating cost.
• Totally closed vibrating screen, less dust to realize environment protection.
• Dual-computer control system, auto/semi-auto/manual switchable. Fault self-diagnosis function makes the operation easy and reliable.
• Environment friendly: Adopting No mix bag filter, the emission is below 50mg/n m³. The recycling function ensure so make full advantage of the waste and avoid second pollution.
• The drying roller is of effective heat preservation. The excellent power-saving burner consumes less fuel.
• The European technology designed mixer is equipped with double reduction motors to ensure better mixing quality. All internal parts of the mixer use high-strength wear-resistant materials to prolong its service life.
• The belt feeder adopts frequency conversion speed control, higher operating efficiency. The belts can be replaced without removing the belt conveyor. Besides, alarm devices are equipped to remind the operator when the machine runs out of the raw material
Main technical parameters of LB series Asphalt Mixing Plant
Model Output Capacity Mixer Capacity Dust Remove Effect Total Power Fuel Oil Fuel Coal
LB500 40t/h 500 kg ≤20 mg/N m³ 147kW 5.5-7 kg/t 10kg/t
LB800 64t/h 800 kg ≤20 mg/N m³ 199kW 5.5-7 kg/t 10kg/t
LB1000 80t/h 1000 kg ≤20 mg/N m³ 285kW 5.5-7 kg/t 10kg/t
LB1200 100t/h 1200kg ≤20 mg/N m³ 316kW 5.5-7 kg/t 10kg/t
LB1500 120t/h 1500 kg ≤20 mg/N m³ 380kW 5.5-7 kg/t 10kg/t
LB2000 160t/h 2000 kg ≤20 mg/N m³ 470kW 5.5-7 kg/t 10kg/t
LB2500 200t/h 2500 kg ≤20 mg/N m³ 547kW 5.5-7 kg/t 10kg/t
LB3000 240t/h 3000 kg ≤20 mg/N m³ 70 kW 5.5-7 kg/t 10kg/t
LB4000 300t/h 4000 kg ≤20mg/N m³ 87 kW 5.5-7 kg/t 10kg/t
LB5000 400t/h 5000 kg ≤20mg/N m³ 96kW 5.5- kg/t 10kg/t
Main structure OF ASPHALT BATCH MIX PLANT
Dryer Drum:
The dryer drum has been designed and developed by using high quality raw materials to ensure long life. The proven flight design ensures a perfect distribution of materials to be dried. Positive drive is provided by means of a ring gear, coupled to a pinion driven by an invert-controlled geared motor. The drum is guided through two rolling steel rings on 4 rollers with bearings mounted on a sturdy mai8n frame.
Burner:
The universal burner of our systems work with either diesel or heavy oil. Special heated adjustable cam is provided to regulate the flame length. A gate with control screw enables the flame to be enlarged or reduced.
Batching Tower:
The batching tower of our systems is fully automatic to offer the best guarantee in terms of product quality. The operator can choose all the required process parameters and all components of the tower will become automatically set to obtain the requested product. The main units of the tower such as elevator, screen, hot aggregate storage bins and mixer are designed for long life, low maintenance and reliability.
Cold Feed Bins:
The plants are provided with abrasion resistant cold freed bins. The bins have self-relieving bottom opening, which eliminates bridging of the feeders. Each bin is provided with variable speed invert drive through geared motor.
Control Unit:
Computerized controls are provided for burner, temperature, damper, emergency plant shut down, sequential start and stop, etc. This display shows production TPH, Aggregate
Pre-sale service
Suggest the best suitable products for customers according to their requirement, with sincere attitude
Try our best to Offer the technical service before installment.
Give our customers training for main problems and solution, maintenance and so on
During sale service
Supervising the whole process of producing and shipment and making sure our product deliver with good condition in time.
Offer all the necessary technical data to customer.
After sale service
Offer installment, debugging, and repairing service after customer receiving our products.
Offer work-site training.
Solve the customer’s complain at first time and try to arrive at the work site once get your notice.
We record every sold product on installment, debugging, and repairing situation. And provide professional maintenance advice.
We will visit customer timely to learn customer’s advice and new demand
Haomei machinery equipment co.,Ltd is located in the famous machinery capital of Zhengzhou, China. We are professional machinery products manufacturer-featuring a wide range of quality asphalt mixing plant, concrete mixer, concrete batching plant, mobile concrete plant, concrete pump, truck pump with boom, truck mixer, etc. We adhere to the policy of "QUALITY FIRST AND INTEGRITY WINS" to cooperate with clients from all over the world. Our company covers over 100 acres with workshop area of more than 50,000 square meters has 5 branches.
Certificates and customers
1. Why dose the customs choose our HAOMEI concrete mixer?
Specialize on manufacturing only asphalt mixing plant
Commitment used to serve clients as their solution partner.
What's the quality of your concrete mixer?
Rest assured that our products have got ISO, CE certificated. We have the professional team for the products' study and development.
What’s more, LDX200Asphalt mixing plant is on sale with a competitive price and I believe you will not miss this chance. We sincerely hope we can establish business relationship between us and welcome you visit our factory.
2. When do you deliver the goods?
less than 30 days after the deposit.
